| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
273-7081
|
Torsion spring |
$20.60
|
1 |
|
usually ships 1-5 days |
2 |
273-7082
|
Squeegee latch shaft |
$20.60
|
1 |
|
usually ships 7-19 days |
3 |
273-7083
|
Squeegee latch bracket |
$59.00
|
1 |
|
usually ships 1-5 days |
4 |
273-7084
|
Swivel mount bracket |
$41.30
|
1 |
|
usually ships 1-5 days |
5 |
173-7235
|
Flanged bushing |
$29.00
|
1 |
|
usually ships 1-5 days |
6 |
173-7236
|
Bracket |
$39.70
|
1 |
|
usually ships 1-5 days |
7 |
999-1261
|
Washer M6 flat stainless steel |
$0.99
|
2 |
|
ships same day |
8 |
999-1020
|
Bolt 1/4-20 x 2 hex head hot dipped galvanized |
$2.57
|
1 |
|
usually ships 11-24 days |
9 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
$0.99
|
1 |
|
ships same day |
10 |
173-8413
|
Nut 1/4 cap |
$0.90
|
2 |
|
usually ships 7-19 days |
11 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
$0.99
|
2 |
|
ships same day |
12 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
$1.18
|
2 |
|
ships same day |
13a |
273-7091
|
Squeegee mount bracket |
$159.03
|
1 |
|
usually ships 7-19 days |
13b |
273-7091
|
Squeegee mount bracket |
$159.03
|
1 |
(after SN 10061300000036, 10061320000182, 10061340000045, 10061360000045) |
usually ships 7-19 days |
14 |
173-7252
|
Bolt 5/16 x 5/8 shoulder stainless steel |
$19.20
|
2 |
|
usually ships 7-19 days |
15 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
$0.99
|
2 |
|
ships same day |
16 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
$0.99
|
2 |
|
ships same day |
17 |
273-7086
|
Washer |
$3.80
|
1 |
|
usually ships 1-5 days |
18 |
273-7087
|
Squeegee lift pad |
$23.40
|
1 |
|
usually ships 7-19 days |
19 |
273-7088
|
Washer nylon (black) |
$1.27
|
2 |
|
usually ships 1-5 days |
20 |
999-0252
|
Screw 5/16-18 x 1 carriage head grade 5 zinc |
$0.99
|
1 |
(after SN 10061300000036, 10061320000182, 10061340000045, 10061360000045) |
ships same day |
21 |
173-3985
|
Washer 7/16 flat stainless steel |
$1.10
|
1 |
(after SN 10061300000036, 10061320000182, 10061340000045, 10061360000045) |
usually ships 7-19 days |
22 |
999-1364
|
Washer 5/16 x 1 fender zinc finish |
$0.99
|
1 |
(after SN 10061300000036, 10061320000182, 10061340000045, 10061360000045) |
ships same day |
23 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
1 |
(after SN 10061300000036, 10061320000182, 10061340000045, 10061360000045) |
ships same day |
24 |
273-7089
|
Deck adjustment bracket |
$25.60
|
1 |
(after SN 10061300000036, 10061320000182, 10061340000045, 10061360000045) |
usually ships 7-19 days |
25 |
273-7090
|
Squeegee linkage assembly |
$306.00
|
1 |
(includes 1-12, 13b, 14-17, 18b, 19-24) |
usually ships 7-19 days |
