| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
273-5424
|
Right hand belt cover |
$20.96
|
1 |
|
usually ships 11-15 days |
2a |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
$0.99
|
2 |
(before SN 10066360001034 for model IM) (after SN 1066400001637 for model IMX) |
ships same day |
2b |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
$0.99
|
4 |
(after SN 10066360001033 for model IM) (after SN 1066400001636 for model IMX) |
ships same day |
3a |
173-8687
|
Screw M4 x 14mm pan head phillips |
$1.90
|
6 |
(before SN 10066360001034 for model IM) (after SN 1066400001637 for model IMX) |
ships same day |
3b |
173-8687
|
Screw M4 x 14mm pan head phillips |
$1.90
|
8 |
(after SN 10066360001033 for model IM) (after SN 1066400001636 for model IMX) |
ships same day |
4 |
173-8688
|
Brush spring clip |
$22.24
|
2 |
|
ships same day |
5 |
273-0095
|
Brush and hub assembly |
$254.23
|
2 |
(includes 9) |
ships same day |
6 |
273-5425
|
Left hand belt cover |
$19.66
|
1 |
|
usually ships 11-15 days |
7 |
273-7174
|
Brush drive assembly |
$224.81
|
2 |
(after SN 10066360001034 for model IM
(after SN 1006640001637 for model IMX) |
usually ships 11-15 days |
8 |
273-5426
|
Screw M5 x 10mm pan head stainless steel |
$2.40
|
6 |
|
usually ships 1-5 days |
9 |
273-0905
|
Brush hub |
$168.31
|
2 |
|
usually ships 11-15 days |
