| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
273-6670
|
Panel harness |
$627.34
|
1 |
|
usually ships 1-5 days |
2 |
273-6671
|
Operator platform harness |
$118.88
|
1 |
|
usually ships 1-5 days |
3 |
273-6672
|
Rotary switch harness |
$21.78
|
1 |
|
usually ships 14-22 days |
4 |
273-6673
|
Main actuator harness |
$85.92
|
|
|
usually ships 1-5 days |
5 |
273-6674
|
Main pot and brake harness |
$134.18
|
1 |
|
usually ships 1-5 days |
6 |
273-6675
|
Main charger harness |
$58.42
|
1 |
|
usually ships 1-5 days |
7 |
273-6676
|
Main traction harness |
$38.26
|
1 |
|
usually ships 1-5 days |
8 |
273-6677
|
Brush harness |
$374.29
|
1 |
|
usually ships 1-5 days |
9 |
273-6678
|
Main power harness |
$255.41
|
1 |
|
usually ships 1-5 days |
10 |
173-7306
|
Main horn harness |
$53.56
|
1 |
|
usually ships 1-5 days |
11 |
273-6679
|
Bag present harness |
$17.49
|
1 |
|
usually ships 1-5 days |
12 |
273-6680
|
Main harness |
$836.85
|
1 |
(shunt sense jumper harness) |
usually ships 1-5 days |
13 |
273-6680
|
Main harness |
$836.85
|
1 |
(shunt sense harness) |
usually ships 1-5 days |
14 |
173-7303
|
Main vacuum harness |
$72.97
|
|
(optional) |
usually ships 1-5 days |
15 |
273-6680
|
Main harness |
$836.85
|
1 |
(braided shunt jumper wire harness) |
usually ships 1-5 days |
16 |
273-6680
|
Main harness |
$836.85
|
1 |
(shunt jumper wire harness) |
usually ships 1-5 days |
17 |
273-6684
|
Lower brake harness |
$71.21
|
1 |
|
usually ships 14-22 days |
18 |
273-6685
|
Lower traction harness |
$88.28
|
1 |
|
usually ships 14-22 days |
