| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
173-7205
|
Left hand frame bracket |
$37.07
|
1 |
|
usually ships 14-22 days |
2 |
173-7206
|
Right hand frame bracket |
$40.70
|
1 |
|
usually ships 14-22 days |
3 |
273-6662
|
Frame assembly (OBSOLETE) |
$438.90
|
1 |
(includes 8-9) |
usually ships 14-22 days |
4 |
173-7208
|
Spacer |
$3.82
|
2 |
|
usually ships 14-22 days |
5 |
173-7209
|
Axle |
$98.45
|
1 |
|
usually ships 14-22 days |
6 |
173-7210
|
Wheel (set of 2) |
$156.22
|
1 |
|
ships same day |
7 |
173-4748
|
External snap ring (OBSOLETE) |
$0.99
|
2 |
|
usually ships 14-22 days |
8 |
999-1489
|
Screw 3/8-16 x 1 1/2 hex head stainless steel |
$1.72
|
2 |
|
ships same day |
9 |
999-0120
|
Washer 3/8 SAE flat |
$0.99
|
2 |
|
ships same day |
