| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
999-1232
|
Screw 5/16-18 x 3/4 hex head stainless steel |
$0.99
|
8 |
|
ships same day |
2 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
8 |
|
ships same day |
3 |
273-0228
|
Latch plate |
$27.94
|
1 |
|
usually ships 1-5 days |
4 |
273-0229
|
Right hand battery tray guide |
$150.70
|
1 |
|
usually ships 1-5 days |
5 |
273-0230
|
Left hand battery tray guide |
$80.85
|
1 |
|
usually ships 1-5 days |
6 |
999-1056
|
Bolt 5/16-18 x 1 shoulder stainless steel |
$32.63
|
2 |
|
ships same day |
7 |
273-0231
|
Thrust washer |
$3.63
|
4 |
|
usually ships 1-5 days |
8 |
273-0232
|
Right hand stop latch |
$16.06
|
1 |
|
usually ships 1-5 days |
9 |
273-0233
|
Latch cover |
$163.90
|
1 |
|
usually ships 1-5 days |
10 |
273-0234
|
Compression spring |
$15.95
|
2 |
|
usually ships 1-5 days |
11 |
273-0235
|
Left hand stop latch |
$16.50
|
1 |
|
usually ships 1-5 days |
12 |
273-0236
|
Extension spring |
$11.66
|
1 |
|
usually ships 1-5 days |
