| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
273-3433
|
Vacuum wiring harness |
$64.15
|
2 |
|
usually ships 1-5 days |
2 |
273-3434
|
Platform wiring harness |
$92.40
|
1 |
|
usually ships 1-5 days |
4 |
273-3436
|
Drive and brake wiring harness |
$120.05
|
1 |
|
usually ships 1-5 days |
5 |
273-3437
|
Horn wiring harness |
$34.17
|
1 |
|
usually ships 1-5 days |
6 |
273-3438
|
Solenoid wiring harness |
$21.07
|
1 |
|
usually ships 1-5 days |
7 |
273-3439
|
Vacuum actuator wiring harness |
$18.81
|
1 |
|
usually ships 1-5 days |
8 |
273-3440
|
Scrub deck actuator wiring harness |
$27.07
|
1 |
|
usually ships 1-5 days |
9 |
273-3441
|
Brush motor wiring harness |
$38.58
|
1 |
|
usually ships 1-5 days |
12 |
173-8349
|
Wire from battery to charger plug (red) |
$62.38
|
1 |
|
usually ships 11-16 days |
13 |
173-8350
|
Wire from battery to charger plug (black) |
$64.15
|
1 |
|
usually ships 11-16 days |
14 |
273-3228
|
Off aisle pump harness |
$72.39
|
1 |
(optional) |
usually ships 1-5 days |
15 |
273-3227
|
Relay and switch harness |
$101.82
|
1 |
(optional) |
usually ships 1-5 days |
N/S |
273-3435
|
Platform wiring harness |
$98.87
|
1 |
|
usually ships 1-5 days |
N/S |
273-3442
|
Main wiring harness |
$220.44
|
1 |
(includes 2 and 4-9) |
usually ships 1-5 days |
N/S |
991-2112
|
175amp charger plug with pins (gray) SB175 |
$16.09
|
1 |
|
ships same day |
