| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-1289
|
Screw 5/16-18 x 2 pan head stainless steel |
4 |
|
|
2 |
273-3192
|
Spacer |
4 |
|
|
3 |
999-0525
|
Nut 5/16-18 flange lock serrated zinc plated |
6 |
|
|
4 |
273-0019
|
Screw 5/16-18 x 5/8 carriage stainless steel |
2 |
|
|
5 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
2 |
|
|
6 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
2 |
|
|
7 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
6 |
|
|
8 |
999-0252
|
Screw 5/16-18 x 1 carriage head grade 5 zinc |
2 |
|
|
9 |
173-3964
|
Thrust washer |
2 |
|
|
10 |
273-5628
|
Flanged bearing |
2 |
|
|
11 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
2 |
|
|
12 |
273-3194
|
Spring hanger bracket |
2 |
|
|
