| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-4131
|
Hose nylon braid |
1 |
|
|
2 |
273-7645
|
Chemical cap( with dip tube) |
1 |
|
|
3 |
273-0179
|
Foot filter |
1 |
|
|
4 |
999-1141
|
Screw 8 x 3/4 pan head phillips zinc plated |
14 |
|
|
5 |
999-1940
|
Screw #10-16 x 1/2 pan head phillips type B stainless steel |
2 |
|
|
6 |
273-7646
|
Full line indicator bracket |
1 |
|
|
7 |
173-8584
|
Tank lid (OBSOLETE) |
1 |
|
|
8 |
173-8585
|
Tank lid gasket |
1 |
|
|
9 |
173-6099
|
Screw 6 x 1/2 sheet metal stainless steel |
1 |
|
|
10 |
173-8262
|
Eye lanyard with loop |
1 |
|
|
11 |
273-7647
|
Machined interim tank |
1 |
|
|
12 |
173-1821
|
Hose clamp |
1 |
|
|
13 |
173-8669
|
Nylon hosebarb npt 1/4 X 3/8 |
1 |
|
|
14 |
273-6779
|
Hose barb |
2 |
|
|
15 |
173-2741
|
Hose clamp |
6 |
|
|
16 |
273-7648
|
Trimmed bottle holder |
1 |
|
|
17 |
173-4128
|
Hose, nylon braid |
2 |
|
|
18 |
273-6781
|
3 way ball valve |
1 |
|
|
19 |
273-5715
|
Hosebarb 1/8 x 1/4 inch |
3 |
|
|
20 |
273-6782
|
On/off panel |
1 |
|
|
21 |
999-1052
|
Bolt 5/16-18 x 3/4 hex head grade 5 zinc plated |
6 |
|
|
22 |
999-1364
|
Washer 5/16 x 1 fender zinc finish |
6 |
|
|
23 |
273-5416
|
Tether |
1 |
|
|
24 |
173-1216
|
Drain hose 1 1/2 x 24 inch |
1 |
|
|
25 |
173-3565
|
3/4 inch nipple fitting |
1 |
|
|
26 |
173-3563
|
3/4 inch female tee fitting |
1 |
|
|
27 |
173-2624
|
Hosebarb 3/4MPT x 1/2 hose |
1 |
|
|
28 |
273-6783
|
Reducer fitting |
1 |
|
|
29 |
273-6784
|
Hose barb |
1 |
|
|
30 |
997-2000
|
Hose clamp |
2 |
|
|
31 |
173-8564
|
Drain plug |
1 |
(service only) |
|
32a |
273-7649
|
Icapsol encapsulating |
1 |
|
|
32b |
273-7650
|
Icapsol encaps |
|
|
|
33 |
273-6787
|
Gasket |
1 |
|
|
