CHARIOT IVACUUM Brush Deck Lift Assembly

#PartDescriptionPriceReqNotesAvailability
1 173-8254 Handle grip (blue) $9.08 1 usually ships 1-5 days
2 173-6083 Squeegee lifting handle $130.90 1 usually ships 7-19 days
3 273-0065 Snap switch $294.80 1 usually ships 7-19 days
4 273-6186 Switch plunger $158.40 1 usually ships 1-5 days
5 173-3153 Clevis pin $6.38 1 usually ships 7-19 days
6 999-0295 Nut 4-40 nylon insert lock stainless steel $0.99 2 ships same day
7 999-0688 Bolt 5/16-18 x 1 1/4 hex head stainless steel $0.99 1 ships same day
8 173-6094 Lifting cable $51.59 1 usually ships 7-19 days
9 999-0423 Nut 5/16-18 nylon insert lock stainless steel $0.99 8 ships same day
10 999-0967 Bolt 5/16-18 x 3/4 carriage head stainless steel $2.16 2 (Deluxe only) ships same day
11 273-0021 Plastic pulley $52.80 4 usually ships 7-19 days
12 273-5945 Pulley retainer bracket $40.70 1 usually ships 1-5 days
13 273-0024 Flanged bearing $9.02 5 usually ships 7-19 days
14 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel $0.99 8 ships same day
15 273-0028 Pulley retainer plate $16.39 1 usually ships 1-5 days
16 273-0016 Mounting plate $53.13 1 usually ships 1-5 days
17 173-3969 Bolt 5/16-18 x 1 1/4 shoulder bolt cap (OBSOLETE) $6.38 4 usually ships 7-19 days
18 173-6088 Handle retainer $33.66 1 (after SN 1000157499) usually ships 1-5 days
20 173-6087 Right hand channel bracket $251.90 1 usually ships 1-5 days
21 999-0423 Nut 5/16-18 nylon insert lock stainless steel $0.99 2 (Deluxe only) ships same day
22 273-6187 Cable mounting bracket $37.73 1 (Deluxe only) usually ships 1-5 days
23 273-0025 Pulley mounting plate $42.24 1 usually ships 1-5 days
24 999-1343 Screw 5/16-18 x 5/8 hex head stainless steel $1.25 1 ships same day
25 173-2815 Washer 33/64 x 1 thrust $7.81 2 usually ships 7-19 days
26 999-0983 Screw 4-40 x 1 pan head phillips zinc plated $0.99 2 ships same day
27 999-1158 Washer #6 flat stainless steel $0.99 2 ships same day
28 173-1130 Cotter ring $2.42 1 ships same day
29 173-5480 Spacer $3.63 1 usually ships 1-5 days
30 999-0252 Screw 5/16-18 x 1 carriage head grade 5 zinc $0.99 1 (Deluxe only) ships same day
31 173-7529 Squeegee cable assembly (OBSOLETE) $149.60 1 (Deluxe only) usually ships 7-19 days
