| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
173-7030
|
Spotter tank (dark gray) (OBSOLETE) |
|
|
|
002 |
173-2720
|
Hosebarb 1/8 MPT 3/8 |
|
|
|
003 |
991-8149
|
1/8 inch male quick disconnect |
|
|
|
004 |
173-7032
|
1/8 close nipple |
|
|
|
005 |
173-1821
|
Hose clamp |
|
|
|
006 |
173-8327
|
Nylon braid 3/8 x 10 inch hose (OBSOLETE) |
|
|
|
007 |
189-4181
|
3/8 inch mesh strainer |
|
|
|
008 |
173-7033
|
Plastic hosebarb 1/8 x 3/8 |
|
|
|
009 |
173-1572
|
Hosebarb 3/8 x 3/8 inch |
|
|
|
010 |
173-7034
|
Rubber hose 3/8 x 17' |
|
|
|
011 |
173-2472
|
Nut 10-32 with star washer |
|
|
|
012 |
173-7035
|
PVC flojet pump L-shaped bracket (OBSOLETE) |
|
|
|
013 |
173-7036
|
120V flojet pump |
|
|
|
014 |
173-7037
|
Rubber hose 3/8 x 11 inches |
|
|
|
015 |
173-7038
|
Lower panel cover plate |
|
|
|
016 |
999-0311
|
Washer #10 external star lock zinc plated |
|
|
|
017 |
999-0371
|
Screw 10-32 x 1/2 pan head phillips zinc plated |
|
|
|
018 |
999-0811
|
Screw 10-32 x 3/8 pan head phillips stainless steel |
|
|
|
019 |
173-7040
|
Vacuum motor plate |
|
|
|
020 |
173-7041
|
115V Spotter vacuum assembly (OBSOLETE) |
|
|
|
021 |
189-0319
|
2 position rocker switch |
|
|
|
022 |
173-2549
|
Bolt 10-32 x 3/8 hex head thread rolling with star washer |
|
|
|
023 |
173-2707
|
18/3 cord set 25 foot (yellow) |
|
|
|
024 |
173-0682
|
Strain relief (OBSOLETE) |
|
|
|
025 |
173-0808
|
Rivet 1/8 x 3/8 |
|
|
|
026 |
173-7042
|
Tension latch keeper (OBSOLETE) |
|
|
|
027 |
173-7043
|
Screw 10-32 x 1 phillips pan head green |
|
|
|
028 |
173-7044
|
Switch/cord spotter plate |
|
|
|
029 |
173-2478
|
Nut 1/2 conduit nickel plated thread (OBSOLETE) |
|
|
|
030 |
173-7045
|
Nylon ratchet clamp 43/64 |
|
|
|
