BD 30/4 Suction Beam Retraction Assembly

#PartDescriptionPriceReqNotesAvailability
1 273-9949 Screw M5 x 12 countersunk $1.32 4 usually ships 7-19 days
2 999-1308 Nut M6-1 hex stainless steel $0.99 1 ships same day
3 999-9100 Washer M5 flat stainless steel $5.83 2 ships same day
4 273-9936 Spring washer $1.28 2 usually ships 7-19 days
5 273-9950 Screw M5 x 35 cylinder head $2.37 2 usually ships 7-19 days
6 273-9951 Splash guard cover $158.40 1 usually ships 7-19 days
7 273-9952 Coupler bracket $266.20 1 usually ships 7-19 days
8 273-9953 Bracket $47.85 1 usually ships 7-19 days
9 273-9954 Plug $21.23 1 usually ships 7-19 days
10 273-9955 Bushing $16.50 2 usually ships 7-19 days
11 273-9956 Seal $38.28 1 usually ships 7-19 days
