| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
273-7107
|
Bag present harness |
$621.46
|
1 |
|
usually ships 11-16 days |
2 |
273-7108
|
Operator platform harness |
$146.30
|
1 |
|
usually ships 1-5 days |
3 |
273-6673
|
Main actuator harness |
$85.92
|
1 |
|
usually ships 1-5 days |
4 |
273-7109
|
Main potentiometer and brake harness |
$180.40
|
1 |
|
usually ships 11-16 days |
5 |
173-7301
|
Main charger harness |
$145.95
|
1 |
|
usually ships 11-16 days |
6 |
173-7302
|
Main traction harness |
$111.82
|
1 |
|
usually ships 11-16 days |
7 |
173-7303
|
Main vacuum harness |
$72.97
|
1 |
|
usually ships 11-16 days |
8 |
173-7304
|
Main brush harness |
$97.11
|
1 |
|
usually ships 1-5 days |
9 |
173-7305
|
Main power harness |
$209.51
|
1 |
|
usually ships 11-16 days |
10 |
173-7306
|
Main horn harness |
$53.56
|
1 |
|
usually ships 1-5 days |
11 |
273-7110
|
Side broom harness |
$226.02
|
1 |
|
usually ships 11-16 days |
12 |
273-7111
|
Vacuum solenoid harness (OBSOELTE) |
$12.21
|
1 |
|
usually ships 11-16 days |
13 |
273-7112
|
Vacuum switch harness |
$72.60
|
1 |
|
usually ships 1-5 days |
14a |
173-7307
|
Charger inhibit jumper |
$32.60
|
1 |
|
usually ships 11-16 days |
14b |
273-7098
|
Charger jumper harness |
$112.41
|
1 |
(On-board charger) |
usually ships 11-16 days |
15a |
273-6684
|
Lower brake harness |
$71.21
|
1 |
(see reference number 3 and 4) |
usually ships 11-16 days |
15b |
273-8932
|
Lower traction cable set |
$41.07
|
1 |
(see reference number 7) |
ships same day |
16a |
273-6685
|
Lower traction harness |
$88.28
|
1 |
(see reference number 3 and 4) |
usually ships 11-16 days |
