| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-5428
|
Vacuum hose |
1 |
|
|
2 |
273-0218
|
Right hand outer bracket |
1 |
|
|
3 |
173-3967
|
Bolt 5/16-18 x 1 1/2 shoulder cap |
2 |
|
|
4 |
173-3184
|
Knob |
2 |
|
|
5 |
273-0219
|
13 inch vac shoe with wiper |
2 |
|
|
6 |
993-0014
|
CUFF, HOSE 1.5 inch BLK A 2161 |
1 |
|
|
7 |
273-1008
|
32 inch skirt bracket |
1 |
|
|
8 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
10 |
|
|
9 |
173-3985
|
Washer 7/16 flat stainless steel |
4 |
|
|
10 |
999-0506
|
Bolt 1/4-20 x 1 1/2 hex head stainless steel |
4 |
|
|
11 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
10 |
|
|
12 |
273-6460
|
Vacuum mounting plate |
2 |
|
|
13 |
273-0221
|
Left hand outer bracket |
1 |
|
|
14 |
273-0222
|
Left hand inner bracket |
1 |
|
|
15 |
273-0223
|
Right hand inner bracket |
1 |
|
|
16 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
4 |
|
|
17 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
8 |
|
|
18 |
173-2815
|
Washer 33/64 x 1 thrust |
8 |
|
|
19 |
173-3963
|
Washer 1/2 thrust |
8 |
|
|
20 |
173-8299
|
Bearing |
4 |
|
|
