| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
273-6840
|
Dispensing cap |
1 |
|
|
2 |
273-0173
|
Storage cap |
2 |
|
|
3 |
273-0178
|
Dispensing cap |
1 |
|
|
4 |
273-0179
|
Foot filter |
2 |
|
|
5 |
273-6841
|
Chemical tank |
1 |
|
|
6 |
999-1480
|
Screw 1/4-20 x 5/8 button head socket cap stainless steel |
4 |
|
|
7 |
273-6842
|
Tank bracket |
1 |
|
|
8 |
173-5420
|
Solution filter assembly |
1 |
|
|
9 |
173-1685
|
Hosebarb 1/2 x 1/2 inch |
2 |
|
|
10 |
273-0174
|
Hosebarb 1/4 x 1/4 |
1 |
|
|
11 |
173-2741
|
Hose clamp |
1 |
|
|
12 |
273-6843
|
Chemical tank |
1 |
|
|
13 |
273-0176
|
Chemical tank decal |
1 |
|
|
14 |
173-1821
|
Hose clamp |
2 |
|
|
