| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-0365
|
Screw 6-32 x 5/8 pan head phillips zinc plated |
1 |
|
|
2 |
173-2774
|
Tank lid |
1 |
|
|
3 |
173-8262
|
Eye lanyard with loop |
1 |
|
|
4 |
999-1542
|
Nut 6-32 acorn stainless steel |
1 |
|
|
5 |
173-8567
|
Tank lid gasket |
1 |
|
|
6 |
173-5336
|
Float cage assembly |
1 |
|
|
7 |
273-6249
|
Adapter |
1 |
|
|
8 |
273-0167
|
Float tube assembly |
1 |
|
|
9 |
997-2007
|
Hose clamp |
1 |
|
|
10 |
189-0329
|
Hose clamp |
4 |
|
|
11 |
173-7349
|
45 degree p-trap hose |
1 |
|
|
12 |
273-6834
|
Recovery tank |
1 |
|
|
13 |
999-1667
|
Screw 5/16-18 x 1 1/4 socket head stainless steel |
2 |
|
|
14 |
273-5721
|
Strap hook |
2 |
|
|
15 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
5 |
|
|
16 |
273-0171
|
Hinge bracket |
1 |
|
|
17 |
999-1343
|
Screw 5/16-18 x 5/8 hex head stainless steel |
7 |
|
|
18 |
273-6835
|
Tank stiffener bracket |
1 |
|
|
19 |
173-1542
|
1 1/2 compression gasket |
2 |
|
|
20 |
173-8564
|
Drain plug |
1 |
|
|
21 |
273-6836
|
Slip joint nut |
2 |
|
|
23 |
173-1216
|
Drain hose 1 1/2 x 24 inch |
1 |
|
|
24 |
173-8264
|
PVC tube 1 1/2 x 24 inch |
1 |
|
|
25 |
173-7348
|
Drain hose lanyard |
1 |
|
|
