| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-8610
|
Gray roller wheel (OBSOLETE) |
2 |
|
|
2 |
173-2667
|
Nut 1/2 starlock push-on |
2 |
|
|
3 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
18 |
|
|
4 |
999-1207
|
Screw 5/16-18 x 2 1/2 hex head stainless steel |
10 |
|
|
5 |
173-4420
|
Pump and wheel mounting frame |
1 |
|
|
6 |
999-0912
|
Bolt 1/4-20 x 3 1/2 18-8 hex head stainless steel |
8 |
|
|
7 |
173-5307
|
Caster wheel assembly |
2 |
|
|
8 |
173-5699
|
Caster mounting plate |
1 |
|
|
9 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
8 |
|
|
