| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
173-0231
|
hose elbow gasket |
|
|
|
002 |
173-0232
|
swivel elbow |
|
|
|
003 |
173-0233
|
hose lock clip |
|
|
|
004 |
173-0234
|
tank plate (OBSOLETE) |
|
|
|
005 |
173-0235
|
Tank plate gasket (OBSOLETE) |
|
|
|
006 |
N/A
|
Not available |
|
(Wet/dry cartridge filter) |
|
007 |
173-0237
|
knob |
|
|
|
008 |
173-0238
|
standoff |
|
|
|
009 |
999-0017
|
Washer 1/4 external star lock |
|
|
|
010 |
173-2473
|
Washer M8 x 25 plated |
|
|
|
011 |
173-0239
|
wet/dry filter cage |
|
|
|
012 |
173-0240
|
vacuum shut-off ball float |
|
|
|
013 |
173-0241
|
float shut-off gasket |
|
|
|
014 |
173-2474
|
Nut 2 nickel plated thread |
|
|
|
015 |
173-0242
|
support basket plate |
|
|
|
016 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
|
|
|
017 |
173-2476
|
Screw 8-18 x 3/8 phillips pan head |
|
|
|
018 |
173-0243
|
front mount keeper |
|
|
|
019 |
173-2477
|
Screw 1 1/4 coarse black deck |
|
|
|
020 |
173-0297
|
10 foot hose for use on all Titans |
|
|
|
021 |
173-0298
|
Squeegee hose 30 inch (OBSOLETE) |
|
|
|
022 |
173-0299
|
1.5 inch cuff |
|
|
|
023 |
173-0300
|
Swivel Cuff |
|
|
|
