| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
173-5632
|
Rest pad |
$187.37
|
1 |
|
usually ships 1-5 days |
2 |
173-5633
|
Seat plate |
$41.91
|
1 |
|
usually ships 1-5 days |
3 |
999-1458
|
Nut 5/16-18 acorn nickel plated |
$0.99
|
4 |
|
ships same day |
4 |
999-0126
|
Washer 1/2 split lock |
$1.28
|
2 |
|
ships same day |
5 |
999-0163
|
Nut 3/8-16 wing zinc plated |
$0.99
|
1 |
|
ships same day |
6 |
999-1482
|
Nut 3/8-16 nylon lock stainless steel |
$1.06
|
1 |
|
ships same day |
7 |
999-0120
|
Washer 3/8 SAE flat |
$0.99
|
3 |
|
ships same day |
8 |
173-5635
|
Left hand seat bracket |
$55.00
|
1 |
|
usually ships 1-5 days |
9 |
173-5636
|
Right hand seat bracket |
$55.00
|
1 |
|
usually ships 1-5 days |
10 |
999-0686
|
Bolt 3/8-16 x 2 3/4 hex head stainless steel |
$2.55
|
1 |
|
ships same day |
11 |
173-1130
|
Cotter ring |
$2.42
|
1 |
|
ships same day |
12 |
173-0418
|
Handle locking lever |
$31.90
|
1 |
|
usually ships 7-19 days |
13 |
173-0419
|
Clevis pin |
$8.47
|
1 |
|
usually ships 7-19 days |
14 |
173-5638
|
4 inch locking rod |
$70.40
|
1 |
|
usually ships 1-5 days |
15 |
173-3944
|
Washer 2/5 nylon |
$2.00
|
2 |
|
usually ships 1-5 days |
16 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
$2.16
|
2 |
|
ships same day |
17 |
173-5639
|
Screw 3/8-16 x 5 flat hex head cap stainless steel |
$16.06
|
1 |
|
usually ships 1-5 days |
18 |
173-1025
|
Knob |
$21.12
|
1 |
|
usually ships 7-19 days |
19 |
173-5640
|
Spacer |
$63.80
|
1 |
|
usually ships 1-5 days |
20 |
173-5641
|
Seat mounting post |
$451.00
|
1 |
|
usually ships 1-5 days |
21 |
999-0476
|
Screw 5/16-18 x 2 carriage head grade 5 zinc |
$0.99
|
2 |
|
ships same day |
22 |
173-5643
|
Seat mounting receiver assembly |
$226.60
|
1 |
|
usually ships 1-5 days |
23 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
4 |
|
ships same day |
24 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
4 |
|
ships same day |
