| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
999-0442
|
Nut 10-24 nylon insert lock stainless steel |
$1.76
|
4 |
|
ships same day |
2 |
173-6101
|
Motor adapter plate |
$25.08
|
1 |
|
usually ships 7-19 days |
3 |
173-6102
|
Spacer plate |
$25.74
|
1 |
|
usually ships 7-19 days |
4 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
3 |
|
ships same day |
5 |
173-6103
|
Mounting plate |
$67.10
|
1 |
|
usually ships 7-19 days |
6a |
173-8565
|
36V 3 stage vacuum motor |
$281.60
|
1 |
|
ships same day |
6b |
173-4105
|
Carbon brush |
$12.21
|
1 |
|
ships same day |
6c |
991-1254
|
Carbon brush (set of 2) |
$3.84
|
1 |
(NON-OEM) |
ships same day |
7 |
173-6104
|
Vacuum motor gasket (OBSOLETE) |
$11.22
|
1 |
|
usually ships 7-19 days |
8 |
173-6105
|
Mounting gasket |
$20.46
|
1 |
|
usually ships 7-19 days |
9 |
173-6106
|
Right chain guard |
$25.85
|
1 |
|
usually ships 1-5 days |
10 |
173-6107
|
Gasket |
$27.39
|
2 |
|
usually ships 7-19 days |
11 |
173-6108
|
Channel cover |
$72.05
|
1 |
|
usually ships 1-5 days |
12 |
999-0333
|
Screw 10-24 x 1/2 pan head phillips stainless steel |
$0.99
|
2 |
|
ships same day |
13 |
173-2576
|
Nut 10-24 tinnerman (OBSOLETE) |
$5.35
|
2 |
|
usually ships 7-19 days |
14 |
173-6109
|
Gasket |
$19.58
|
1 |
(after SN 1000143552) |
usually ships 7-19 days |
15 |
173-6110
|
Gasket |
$31.46
|
2 |
(after SN 1000143552) |
ships same day |
