LIGHTNING LB2000 Wiring Assembly

#PartDescriptionPriceReqNotesAvailability
1 173-4704 Screw M3-.5 x 40mm pan head thread forming $7.26 2 usually ships 14-22 days
2 173-4705 Washer M4 shakeproof $1.21 2 usually ships 14-22 days
3 173-0923 Spring $2.00 1 usually ships 14-22 days
4 173-0378 25amp switch replacement $65.45 2 ships same day
5 173-4697 Screw M4-.8 x 10mm hex head thread forming $2.00 3 ships same day
6 173-4706 Washer M5 shakeproof $1.39 3 usually ships 14-22 days
7 173-1800 5/16 nylon clamp (OBSOLETE) $0.99 1 usually ships 14-22 days
8 173-2846 Spacer $4.36 1 usually ships 14-22 days
9 173-2845 Strain relief $20.35 1 usually ships 14-22 days
10 173-2844 Cord end boot $4.11 1 usually ships 14-22 days
11 173-8469 14/3 x 38 inch pigtail cord $39.38 1 usually ships 14-22 days
12 189-0312 3/8 inch circuit breaker boot $59.75 1 usually ships 14-27 days
13a 173-0335 14/3 yellow power cord set 50 ft (with strain relief) $162.02 1 ships same day
13b 991-5005 14/3 replacement power cord 50 foot (yellow) $108.51 1 (NON-OEM) (does not include strain relief) ships same day
13c 991-5001 14/3 extension cord 50 foot (yellow) $103.23 1 (NON-OEM) ships same day
14 173-7427 14amp circuit breaker $46.29 1 ships same day
15 173-4765 Barrier sheet $3.15 1 usually ships 14-22 days
16 173-9861 Filter assembly $67.10 1 (230V) usually ships 1-5 days
17 173-9862 Wire $7.21 1 usually ships 1-5 days
18 999-9100 Washer M5 flat stainless steel $5.83 1 ships same day
