| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
273-0580
|
Brush deck bracket harness brush |
$17.27
|
1 |
|
usually ships 7-19 days |
2 |
273-0581
|
Brush deck bracket harness sidebroom |
$5.83
|
1 |
|
usually ships 7-19 days |
3 |
273-0582
|
Brush motor thermistor |
$66.00
|
1 |
|
usually ships 7-19 days |
4 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
$0.99
|
2 |
|
ships same day |
5 |
273-5587
|
Brush end cap shaft assembly |
$75.36
|
2 |
|
ships same day |
6 |
999-9151
|
Screw #10-32 x 1/2 truss head phillips |
$0.99
|
2 |
|
usually ships 11-24 days |
7a |
273-6742
|
Cylindrical brush |
$147.42
|
2 |
|
ships same day |
7b |
273-6963
|
Scrubbing brush soft floor - CYLINDRICAL |
$91.30
|
1 |
(optional) |
usually ships 7-19 days |
7c |
273-6962
|
Scrubbing brush hard floor - CYLINDRICAL |
$115.50
|
1 |
(optional) |
usually ships 7-19 days |
8 |
999-1480
|
Screw 1/4-20 x 5/8 button head socket cap stainless steel |
$0.99
|
2 |
|
ships same day |
9 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
3 |
|
ships same day |
10 |
999-0442
|
Nut 10-24 nylon insert lock stainless steel |
$1.76
|
2 |
|
ships same day |
11 |
173-1709
|
P clamp (OBSOLETE) |
$2.30
|
1 |
|
usually ships 7-19 days |
12 |
273-0583
|
Side broom p-clip |
$26.84
|
1 |
|
usually ships 7-19 days |
