| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-9899
|
Top cover - Orange (OBSOLETE) |
1 |
|
|
2 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
3 |
|
|
3 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
10 |
|
|
4 |
173-8234
|
Hinge (cover to tank) |
1 |
|
|
5 |
999-1232
|
Screw 5/16-18 x 3/4 hex head stainless steel |
4 |
|
|
6 |
173-8235
|
Left tank bracket |
1 |
|
|
7 |
173-8236
|
Right tank bracket |
1 |
|
|
8 |
173-1772
|
P clamp |
1 |
|
|
9 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
1 |
|
|
11 |
999-1232
|
Screw 5/16-18 x 3/4 hex head stainless steel |
3 |
|
|
N/S |
173-8237
|
Cargo net with hooks |
1 |
|
|
