| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
273-6108
|
36V brush motor (OBSOLETE) |
2 |
|
|
1b |
173-1576
|
Carbon brush (pkg of 4) |
1 |
|
|
2 |
999-0028
|
Washer 5/16 split lock plain finish |
2 |
|
|
3 |
273-0990
|
Rear squeegee strap |
1 |
|
|
4 |
273-0946
|
Skirt gum rubber rear |
1 |
|
|
5 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
10 |
|
|
6 |
273-0991
|
28 inch scrub deck |
1 |
|
|
7 |
999-1099
|
Bolt 1/4-20 x 3/4 hex head stainless steel |
8 |
|
|
8 |
173-2569
|
Washer .77 x 1.31 flat stainless steel |
2 |
|
|
9 |
189-0323
|
Square keyway |
2 |
|
|
10 |
173-1569
|
Star drive hub |
2 |
|
|
11 |
999-0034
|
Washer 3/8 split lock plain finish |
8 |
|
|
12 |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
2 |
|
|
13 |
999-1364
|
Washer 5/16 x 1 fender zinc finish |
2 |
|
|
14 |
273-0944
|
Front skirt |
1 |
|
|
15 |
173-4130
|
Nut 3/8 plastic nickel plated thread (OBSOLETE) |
2 |
|
|
16 |
273-6110
|
Front skirt strap |
1 |
|
|
17 |
999-0513
|
Nut 3/8-16 nylon insert lock type NE stainless steel |
3 |
|
|
18 |
189-0326
|
Bumper wheel |
2 |
|
|
19 |
999-9094
|
Screw 3/8-16 x 3 hex head stainless steel |
1 |
|
|
20 |
173-1572
|
Hosebarb 3/8 x 3/8 inch |
2 |
|
|
21 |
173-1095
|
Tee fitting |
1 |
|
|
22a |
173-1098
|
36V solenoid valve |
1 |
|
|
22b |
173-8324
|
Solenoid diaphragm |
1 |
|
|
22c |
173-8325
|
Solenoid spring kit |
1 |
|
|
23 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
10 |
|
|
24 |
173-3054
|
Nylon braided hose |
1 |
|
|
25 |
173-1570
|
Nylon braided hose 3/8 x 7 inch |
2 |
|
|
26 |
273-0992
|
Nylon braided hose 1/2 x 17 inch |
1 |
|
|
27 |
173-1821
|
Hose clamp |
1 |
|
|
28 |
173-1025
|
Knob |
2 |
|
|
29 |
173-3944
|
Washer 2/5 nylon |
4 |
|
|
30 |
999-1416
|
Washer 7/16 flat stainless steel |
2 |
|
|
31 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
2 |
|
|
