| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
273-6145
|
Floor pad |
1 |
|
|
2 |
999-1232
|
Screw 5/16-18 x 3/4 hex head stainless steel |
2 |
|
|
3 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
7 |
|
|
4 |
999-0911
|
Screw 5/16-18 x 3 hex head stainless steel |
5 |
|
|
5 |
273-6142
|
Floor plate |
1 |
|
|
6 |
273-6143
|
Bumper cover |
1 |
|
|
7 |
273-6144
|
Step pad |
1 |
|
|
