| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
4 |
|
ships same day |
2 |
999-0130
|
Screw 5/16-18 x 3/4 socket head alloy plain finish |
$0.99
|
2 |
|
ships same day |
3 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
$3.85
|
9 |
|
usually ships 19-32 days |
4 |
173-9998
|
Right retaining band |
$39.44
|
1 |
|
usually ships 1-5 days |
5a |
173-9999
|
12 inch right gum rubber blade |
$62.98
|
1 |
|
usually ships 11-16 days |
5b |
173-9997
|
12 inch right urethane blade (OBSOLETE) |
$67.10
|
1 |
|
usually ships 11-16 days |
6 |
173-9838
|
Right skirt bracket |
$120.05
|
1 |
|
usually ships 11-16 days |
7 |
173-3184
|
Knob |
$51.67
|
2 |
|
ships same day |
8 |
999-0544
|
Screw 5/16-18 x 2 1/4 socket head stainless steel |
$1.78
|
2 |
|
ships same day |
9 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
$1.18
|
9 |
|
ships same day |
10 |
173-9840
|
Left skirt bracket |
$120.05
|
1 |
|
usually ships 1-5 days |
11a |
173-9841
|
12 inch left gum rubber blade |
$74.15
|
1 |
|
usually ships 11-16 days |
11b |
173-9842
|
12 inch left urethane blade |
$80.04
|
1 |
|
ships same day |
12 |
173-9843
|
Left retaining band |
$46.02
|
1 |
|
usually ships 1-5 days |
13 |
173-9844
|
Clevis pin |
$19.31
|
2 |
|
usually ships 11-16 days |
14 |
173-9845
|
Left mounting bracket |
$96.80
|
1 |
|
usually ships 11-16 days |
15 |
173-1593
|
Cotter ring (OBSOLETE) |
$0.99
|
2 |
|
usually ships 11-16 days |
16 |
173-9846
|
Right mounting bracket |
$96.80
|
1 |
|
usually ships 11-16 days |
17 |
173-9847
|
Right side skirt assembly |
$234.22
|
1 |
(includes 3-6 and 9) |
usually ships 11-16 days |
18 |
173-9848
|
Left side skirt assembly |
$258.94
|
1 |
(includes 3 and 9-12) |
usually ships 11-16 days |
