# | Part | Description | Price | Req | Notes | Availability |
001 |
173-5137
|
Bearing (OBSOLETE) |
$5.50
|
2 |
|
usually ships 1-5 days |
002 |
173-5138
|
Support bracket assembly (OBSOLETE) |
$48.95
|
1 |
|
usually ships 1-5 days |
003 |
173-5139
|
Spring support block (OBSOLETE) |
$38.03
|
1 |
|
usually ships 1-5 days |
004 |
173-5140
|
Square cable bracket assembly (OBSOLETE) |
$101.02
|
1 |
|
usually ships 1-5 days |
005 |
173-5141
|
Square pivot bracket assembly |
$159.82
|
1 |
|
usually ships 1-5 days |
006 |
173-5142
|
Bushing |
$3.85
|
1 |
|
usually ships 1-5 days |
007 |
173-3195
|
Swivel caster wheel |
$124.30
|
2 |
|
ships same day |
008 |
173-5143
|
Spring retainer cap (OBSOLETE) |
$15.31
|
2 |
|
usually ships 1-5 days |
009 |
173-7529
|
Squeegee cable assembly (OBSOLETE) |
$149.60
|
1 |
|
usually ships 7-19 days |
010 |
173-5144
|
Roller assembly support |
$133.10
|
2 |
|
usually ships 1-5 days |
011 |
173-5145
|
5/16-18 x 1 stud knob |
$19.29
|
2 |
|
usually ships 1-5 days |
013 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
$0.99
|
|
|
ships same day |
015 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
$0.99
|
3 |
|
ships same day |
016 |
173-3872
|
Squeegee camber lock nut |
$13.98
|
1 |
|
usually ships 1-5 days |
017 |
173-3886
|
Nut 1/2-13 lock thin |
$2.85
|
1 |
|
usually ships 1-5 days |
018 |
173-5027
|
Nut 1/4-20 wing locking |
$2.97
|
7 |
|
usually ships 7-19 days |
019 |
173-5147
|
Squeegee plate rear retaining |
$34.32
|
2 |
|
usually ships 7-19 days |
020 |
173-5148
|
Squeegee plate front retaining |
$90.38
|
1 |
|
usually ships 1-5 days |
022 |
173-5149
|
Pivot axle assembly |
$39.68
|
1 |
|
usually ships 1-5 days |
023 |
173-5121
|
Cable pulley |
$0.99
|
1 |
|
usually ships 1-5 days |
025 |
173-5150
|
Squeegee adjustment plate |
$339.90
|
1 |
|
usually ships 1-5 days |
026 |
173-4599
|
Squeegee mount plate weldment (OBSOLETE) |
$57.34
|
1 |
|
usually ships 1-5 days |
027 |
173-1726
|
Clevis pin |
$4.49
|
2 |
|
usually ships 1-5 days |
028 |
173-5160
|
Squeegee weldment |
$690.80
|
1 |
|
usually ships 1-5 days |
029 |
173-2797
|
Rivet |
$1.57
|
4 |
|
usually ships 7-19 days |
030 |
173-5152
|
Rod weldment square lift |
$52.47
|
1 |
|
usually ships 1-5 days |
031 |
999-9072
|
Bolt 1/4-20 x 1 hex head cap |
$7.32
|
1 |
|
ships same day |
032 |
999-0350
|
Bolt 3/8-16 x 1 1/2 hex head grade 5 zinc plated |
$0.99
|
2 |
|
ships same day |
033 |
173-5154
|
Bolt 3/8OD x 5/8L shoulder |
$13.64
|
2 |
|
usually ships 1-5 days |
034 |
173-1228
|
Bolt 5/16 OD x 1/2 long shoulder |
$4.29
|
1 |
|
usually ships 1-5 days |
035 |
999-1052
|
Bolt 5/16-18 x 3/4 hex head grade 5 zinc plated |
$0.99
|
11 |
|
ships same day |
036 |
173-5155
|
Extension spring |
$12.76
|
2 |
|
usually ships 7-19 days |
037 |
173-5156
|
Spring compress 1.10 x 2.75 x .142 (OBSOLETE) |
$13.08
|
1 |
|
usually ships 1-5 days |
038 |
173-5123
|
Tube |
$15.95
|
1 |
|
usually ships 1-5 days |
039 |
173-5157
|
Squeegee blade 24 inch die cut front (OBSOLETE) |
$59.40
|
1 |
|
usually ships 7-19 days |
040 |
173-5158
|
Squeegee blade 24 inch die cut rear (OBSOLETE) |
$83.60
|
1 |
|
usually ships 7-19 days |
041 |
173-5159
|
Squeegee assembly |
$1,015.30
|
1 |
|
usually ships 1-5 days |
043 |
173-3189
|
Nylon spacer |
$1.57
|
1 |
|
usually ships 1-5 days |
045 |
173-1480
|
Cotter ring |
$2.12
|
3 |
|
ships same day |
046 |
173-3996
|
Washer 3/8in ID x 1x 0.1 neoprene |
$3.96
|
4 |
|
usually ships 1-5 days |
047 |
173-0412
|
Squeegee strap latch |
$47.20
|
1 |
|
usually ships 7-12 days |
048 |
170-7029
|
Keeper |
$3.75
|
1 |
|
ships same day |
049 |
173-1025
|
Knob |
$21.12
|
1 |
|
usually ships 7-19 days |
050 |
173-1842
|
compound spring |
$18.04
|
1 |
|
usually ships 7-19 days |
051 |
173-5161
|
Washer spherical male half |
$23.54
|
2 |
|
usually ships 1-5 days |
052 |
999-0998
|
Washer #10 flat stainless steel |
$0.99
|
6 |
|
ships same day |
056 |
173-3028
|
Roller wheel |
$33.56
|
2 |
|
ships same day |
057 |
999-0187
|
Washer 1/2 flat plain finish |
$0.99
|
1 |
|
ships same day |
058 |
999-0028
|
Washer 5/16 split lock plain finish |
$0.99
|
11 |
|
ships same day |
059 |
173-2483
|
Washer 1/4ID x 3/4OD plated |
$0.99
|
1 |
|
usually ships 1-5 days |
060 |
173-5162
|
Washer 5/8 x 1/2 inch |
$1.85
|
1 |
|
usually ships 1-5 days |
061 |
173-5163
|
Washer 5/8 x 2O x 3/32 thick |
$18.15
|
2 |
|
usually ships 1-5 days |
062 |
189-0326
|
Bumper wheel |
$29.04
|
2 |
|
usually ships 11-24 days |
