| # | Part | Description |
Req | Notes | Availability |
|---|
333 |
173-1139
|
5/8 nylon clamp |
|
|
|
334 |
173-2472
|
Nut 10-32 with star washer |
|
|
|
335 |
173-1873
|
36V motor controller |
|
|
|
336 |
173-1141
|
Spacer |
|
|
|
339 |
999-0006
|
Washer 3/16 flat zinc plated |
|
|
|
340 |
173-1142
|
6-36VDC speed solenoid |
|
|
|
341 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
|
|
|
342 |
999-0018
|
Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated |
|
|
|
343 |
173-1143
|
50mV 70 amp Shunt (OBSOLETE) |
|
|
|
344 |
991-1227
|
36V solenoid 4 post (2 large 2 small) |
|
|
|
345 |
173-1145
|
Insulated stand-off |
|
|
|
346 |
173-1146
|
1/4-20 x 1.25 stud |
|
|
|
347 |
991-1632
|
25amp circuit breaker |
|
|
|
349 |
999-0051
|
Washer #6 medium split lock |
|
|
|
350 |
173-1147
|
Warning Explosion label |
|
|
|
351 |
173-3892
|
Nut 7/16-28 panel (OBSOLETE) |
|
|
|
352 |
N/A
|
Not available |
|
(not available) |
|
353 |
999-0148
|
Washer #6 external star lock zinc plated |
|
|
|
354 |
999-1111
|
Screw 6-32 x 3/4 pan head phillips sheet metal |
|
|
|
355 |
173-1149
|
Stride battery charger wire assembly (OBSOLETE) |
|
|
|
356 |
991-1629
|
35amp circuit breaker |
|
|
|
358 |
999-0143
|
Nut 3/8-24 hex plain finish |
|
|
|
359 |
173-1152
|
Trident rear tower Harness S/N 4001279 & up (OBSOLETE) |
|
|
|
360 |
173-1153
|
Trident chassis harness S/N 4001279 & up (OBSOLETE) |
|
|
|
361a |
173-1154
|
SPST 15amp rocker switch |
|
|
|
361b |
173-1155
|
key kit switch |
|
|
|
362 |
173-1156
|
SPDT 15A European rocker switch (OBSOLETE) |
|
|
|
363 |
189-0317
|
50amp meter |
|
|
|
364 |
173-1158
|
DPDT 15A European rocker switch |
|
|
|
365 |
173-1159
|
36V battery charge meter |
|
|
|
366 |
173-1160
|
LED hour meter |
|
|
|
367 |
173-1161
|
control trident panel (OBSOLETE) |
|
|
|
368 |
173-1162
|
trident control panel harness S/N 4001279 & up (OBSOLETE) |
|
|
|
369 |
173-1163
|
trident control panel label (OBSOLETE) |
|
|
|
370 |
173-5025
|
Screw 6-32 x 1/2 zinc truss head |
|
|
|
371 |
173-2522
|
Nut 6-32 with star washer |
|
|
|
372 |
173-1164
|
Meter retaining plate |
|
|
|
373 |
173-4054
|
Diode assembly |
|
|
|
374 |
999-0147
|
Screw 6-32 x 3/8 round head slotted zinc plated |
|
|
|
375 |
999-0148
|
Washer #6 external star lock zinc plated |
|
|
|
376 |
999-0377
|
Washer 6 SAE flat plain finish |
|
|
|
377 |
173-3909
|
Nut 6-32 hex brass |
|
|
|
