| # | Part | Description |
Req | Notes | Availability |
|---|
E1 |
172-9141
|
120V heater |
1 |
|
|
H2 |
209-0671
|
Light (green) |
1 |
|
|
M1a |
N/A
|
Not available |
1 |
(motor for 300 or 400 PSI) (only available in KIT1) |
|
M1b |
N/A
|
Not available |
1 |
(100 PSI pump) (only available in KIT2) |
|
M2a |
209-0330
|
120V 3 stage vacuum motor |
1 |
(vac motor 209-0330 replaces vac motor 408G as of 12/29/2014) |
|
M2b |
209-0658
|
Carbon brush kit |
1 |
(for 408G) |
|
P1 |
209-0672
|
Hour meter |
1 |
|
|
S1 |
209-0286
|
On/off switch 3 prong |
1 |
(formerly 4 prong and has been replaced by 3 prong which will work in its place) |
|
S2 |
209-0286
|
On/off switch 3 prong |
1 |
(formerly 4 prong and has been replaced by 3 prong which will work in its place) |
|
S3 |
209-0286
|
On/off switch 3 prong |
1 |
(formerly 4 prong and has been replaced by 3 prong which will work in its place) |
|
S4 |
N/A
|
Not available |
1 |
(thermostat) |
|
S5 |
N/A
|
Not available |
1 |
(part of E1) |
|
KIT1 |
172-9140
|
100PSI pump kit |
1 |
(includes M1a) |
|
KIT2 |
209-0667
|
Pump kit |
1 |
(includes M1b) |
|
