| # | Part | Description | Price | Req | Notes | Availability |
|---|
CB1 |
272-6696
|
50amp circuit breaker |
$58.48
|
1 |
(drive wheel) |
usually ships 16-41 days |
CB2 |
991-1628
|
5amp circuit breaker |
$13.40
|
1 |
(control circuit) |
usually ships 16-41 days |
CB3 |
272-7727
|
20amp circuit breaker |
$28.46
|
1 |
(vacuum motor) |
ships same day |
CB4 |
272-6708
|
25amp circuit breaker |
$19.45
|
1 |
(brush motor) |
ships same day |
D1 |
172-0236
|
Diode rectifier assembly |
$31.83
|
1 |
|
ships same day |
D2 |
172-4139
|
35amp rectifier |
$13.40
|
1 |
|
ships same day |
E1 |
272-6703
|
Speed controller |
$574.78
|
1 |
|
usually ships 16-41 days |
E2 |
270-8393
|
24V onboard battery charger |
$675.09
|
1 |
(onboard battery charger 272-9824 has been replaced by 270-8393. For replacement, order onboard charger kit 272-8617) |
usually ships 16-41 days |
F1a |
172-8836
|
150amp fuse |
$19.15
|
1 |
|
usually ships 16-41 days |
F1b |
991-3061
|
150amp fuse |
$48.06
|
1 |
|
ships same day |
H1 |
170-9221
|
Buzzer |
$76.52
|
1 |
|
usually ships 1-5 days |
K1 |
272-6701
|
Solid state relay |
$276.53
|
1 |
|
usually ships 16-41 days |
K2 |
272-8794
|
24V contactor |
$91.00
|
1 |
|
usually ships 16-41 days |
L1 |
272-9265
|
Solenoid valve |
$246.26
|
1 |
|
usually ships 16-41 days |
M1 |
272-6777
|
Drive wheel motor |
$2,311.11
|
1 |
|
ships same day |
M2 |
272-2175
|
Chemical pump |
$290.92
|
1 |
|
usually ships 16-41 days |
M3 |
272-6768
|
Actuator kit |
$730.73
|
1 |
|
usually ships 16-41 days |
M4 |
991-1230
|
24V 3 stage vacuum motor tangential with snout |
$211.00
|
1 |
|
ships same day |
M5 |
272-6726
|
Disk brush motor |
$1,714.77
|
1 |
|
usually ships 1-5 days |
S1a |
172-3785
|
Key switch with two keys |
$64.90
|
1 |
(includes S1b) |
usually ships 1-5 days |
S1b |
991-1634
|
Key (pkg of 2) |
$10.67
|
1 |
|
ships same day |
S4 |
272-6704
|
Emergency stop |
$80.86
|
1 |
|
ships same day |
