| # | Part | Description |
Req | Notes | Availability |
|---|
A1 |
372-3326
|
Control board kit |
1 |
|
|
A2 |
272-3514
|
Speed control |
1 |
|
|
BT1 |
N/A
|
Not available |
1 |
(battery) |
|
CB1a |
172-2523
|
70amp circuit breaker |
1 |
(OEM) |
|
CB1b |
991-1633
|
70amp circuit breaker |
1 |
(NON-OEM) |
|
CB2 |
272-9374
|
10amp circuit breaker |
1 |
|
|
F1a |
172-8836
|
150amp fuse |
1 |
(OEM) |
|
F1b |
991-3061
|
150amp fuse |
1 |
(NON-OEM) |
|
H1 |
172-8839
|
Backup alarm |
1 |
|
|
K1 |
272-8794
|
24V contactor |
1 |
|
|
K2a |
172-2163
|
24V solenoid 4 post (2 large 2 small) |
1 |
(OEM) |
|
K2b |
991-1226
|
24V solenoid 4 post (2 large 2 small) |
1 |
(NON-OEM) |
|
L1 |
272-5312
|
24V solenoid valve |
1 |
|
|
L2 |
272-5312
|
24V solenoid valve |
1 |
|
|
L3 |
272-5312
|
24V solenoid valve |
1 |
|
|
LP1 |
272-7513
|
Beacon assembly |
1 |
(optional) |
|
M1 |
272-8807
|
Drive wheel motor |
1 |
|
|
M2 |
272-2175
|
Chemical pump |
1 |
|
|
M3 |
272-7469
|
24V actuator motor |
1 |
|
|
M4 |
272-7470
|
Lift actuator assembly |
1 |
|
|
M5 |
272-9271
|
Vacuum motor |
1 |
|
|
M6 |
272-9271
|
Vacuum motor |
1 |
|
|
M7 |
272-2148
|
24V brush motor |
1 |
|
|
M8 |
272-2148
|
24V brush motor |
1 |
|
|
M9 |
272-8540
|
24V pump |
1 |
|
|
R1 |
N/A
|
Not available |
1 |
(part of foot pedal assembly) |
|
S1 |
272-2195
|
Key switch assembly |
1 |
|
|
S2 |
272-9417
|
Seat switch |
1 |
|
|
S4 |
172-9233
|
Emergency stop button |
1 |
|
|
Y1 |
272-8811
|
Parking brake |
1 |
|
|
N/S |
272-2358
|
24V onboard battery charger |
1 |
|
|
