| # | Part | Description |
Req | Notes | Availability |
|---|
000 |
N/A
|
Not available |
1 |
|
|
001 |
999-0018
|
Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated |
12 |
|
|
002 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
003 |
999-0120
|
Washer 3/8 SAE flat |
2 |
|
|
004 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
2 |
|
|
005 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
2 |
|
|
006 |
999-0132
|
Bolt 5/16-18 x 3/4 hex head grade 5 zinc plated |
2 |
|
|
007 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
3 |
|
|
008 |
999-0188
|
Nut 3/8-16 nylon insert lock zinc plated |
4 |
|
|
009 |
999-0793
|
Screw 10-24 x 3/8 hex washer slot thread cutting zinc |
2 |
|
|
010 |
999-0273
|
Screw 1/4-20 x 1/2 hex washer head thread rolling zinc |
1 |
|
|
011 |
999-0193
|
Screw 10-24 x 5/8 pan head slotted thread cutting zinc |
3 |
|
|
012 |
999-1255
|
Screw 1/4-20 x 5/8 flat head phillips thread forming |
2 |
|
|
013 |
N/A
|
Not available |
3 |
(Screw) |
|
014 |
997-2008
|
Hose clamp |
6 |
|
|
015 |
272-3434
|
Tail light lens |
1 |
|
|
016 |
272-3435
|
Radiator mount bracket (OBSOLETE) |
1 |
|
|
017 |
272-3436
|
Radiator hose (OBSOLETE) |
1 |
|
|
018 |
272-3437
|
Tube weldment (OBSOLETE) |
1 |
|
|
019 |
272-3438
|
Shroud weldment (OBSOLETE) |
1 |
|
|
020 |
272-3439
|
Lower radiator hose |
2 |
|
|
021 |
N/A
|
Not available |
1 |
(Hydraulic oil cooler) |
|
022 |
N/A
|
Not available |
1 |
|
|
023 |
N/A
|
Not available |
1 |
|
|
024 |
N/A
|
Not available |
1 |
|
|
025 |
N/A
|
Not available |
1 |
|
|
026 |
N/A
|
Not available |
1 |
|
|
027 |
272-3441
|
Gasket bulb (OBSOLETE) |
2 |
|
|
028 |
N/A
|
Not available |
1 |
|
|
029 |
272-3442
|
Gasket bulb |
1 |
|
|
030 |
272-3443
|
Hose band clamp |
2 |
|
|
031 |
272-3444
|
Gasket (OBSOLETE) |
1 |
|
|
032 |
272-3445
|
Strip gasket (OBSOLETE) |
2 |
|
|
033 |
272-3446
|
Connector barb (OBSOLETE) |
1 |
|
|
034 |
N/A
|
Not available |
1 |
|
|
035 |
N/A
|
Not available |
1 |
|
|
