| # | Part | Description |
Req | Notes | Availability |
|---|
000 |
272-3265
|
Propane assembly (OBSOLETE) |
1 |
|
|
001 |
172-0212
|
Hose tube (sold by the foot) |
14 in |
|
|
002 |
N/A
|
Not available |
2 in |
|
|
003 |
997-2005
|
Hose clamp |
4 |
|
|
004 |
272-3263
|
Flexible air inlet hose |
1 |
|
|
005 |
N/A
|
Not available |
1 |
(Propane injector assembly) (includes 041 and 042) (Before SN 1359052) |
|
006a |
N/A
|
Not available |
1 |
(After SN 1359051) |
|
006b |
272-3335
|
Regulator assembly 24 psi (OBSOLETE) |
1 |
(Before SN 1359052) |
|
007 |
272-3336
|
Filter assembly |
1 |
|
|
008 |
272-2172
|
Reducer barb |
1 |
|
|
009 |
997-2003
|
Hose clamp |
2 |
|
|
010 |
272-3337
|
Tee |
1 |
|
|
011 |
272-3338
|
LPG hose assembly |
1 |
|
|
012 |
272-3339
|
LPG hose assembly |
1 |
|
|
013 |
272-3340
|
Male elbow |
1 |
|
|
014 |
272-3341
|
Heater hose |
1 |
|
|
015 |
999-0267
|
Screw 10-24 x 1/2 pan head phillips zinc |
1 |
|
|
016 |
999-0031
|
Bolt 5/16-18 x 1 hex head grade 5 zinc plated |
3 |
|
|
017 |
172-2326
|
Elbow |
2 |
|
|
018 |
272-3342
|
Hose (OBSOLETE) |
1 |
|
|
019a |
272-3343
|
Primary LPG regulator assembly 12 psi (OBSOLETE) |
1 |
(After SN 1359051) |
|
019b |
272-3344
|
Primary regulator (OBSOLETE) |
1 |
(Before SN 1359052) |
|
020a |
272-3345
|
Secondary LPG regulator assembly (OBSOLETE) |
1 |
(After SN 1359051) |
|
020b |
272-3346
|
Secondary regulator (OBSOLETE) |
1 |
(Before SN 1359052) |
|
021 |
172-4075
|
90 degree street elbow |
1 |
|
|
022 |
272-3348
|
Adapter 5/8 x 3/8 NPT barb |
2 |
|
|
023 |
272-3340
|
Male elbow |
4 |
|
|
024 |
272-3350
|
Regulator bracket (OBSOLETE) |
1 |
|
|
025 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
1 |
|
|
026 |
272-3351
|
P clamp |
1 |
|
|
027 |
172-0299
|
Brass elbow |
1 |
|
|
029 |
172-4330
|
Nut 7/8-14 hex jam |
1 |
|
|
030 |
272-3353
|
Switch N C Pressure |
1 |
|
|
031 |
272-3338
|
LPG hose assembly |
1 |
|
|
032 |
272-3355
|
45 degree elbow, male |
2 |
|
|
033 |
272-3356
|
1/4 NPT vent |
1 |
|
|
034 |
272-3357
|
Bulkhead fitting |
1 |
|
|
035 |
999-0188
|
Nut 3/8-16 nylon insert lock zinc plated |
1 |
|
|
036 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
6 |
|
|
037 |
272-3358
|
LP tank cradle (OBSOLETE) |
1 |
|
|
038 |
999-0275
|
Screw 1/4-20 x 3/4 hex washer hd unslotted thread rolling |
6 |
|
|
039 |
272-3359
|
LP tank |
1 |
|
|
040 |
272-3360
|
Locator pin (OBSOLETE) |
1 |
|
|
041 |
N/A
|
Not available |
1 |
(Lpfilter) |
|
042 |
272-3362
|
LP fuel lock-off (OBSOLETE) |
1 |
|
|
043 |
172-8310
|
Grommet |
1 |
|
|
044 |
272-3351
|
P clamp |
1 |
|
|
045 |
272-3330
|
Hose band clamp |
2 |
|
|
046 |
272-3331
|
Hose band clamp (OBSOLETE) |
2 |
|
|
