| # | Part | Description | Price | Req | Notes | Availability |
|---|
001a |
272-0592
|
18/3 power cord 50 foot (yellow) |
$48.32
|
1 |
(OEM) |
usually ships 16-41 days |
001b |
991-5007
|
18/3 replacement power cord 50 foot (black) |
$32.10
|
1 |
(NON-OEM) |
ships same day |
001c |
991-5002
|
16/3 extension cord 50 foot (yellow) |
$48.73
|
1 |
|
ships same day |
001d |
991-5006
|
16/3 replacement power cord 50 foot (yellow) |
$37.50
|
1 |
(NON-OEM) |
ships same day |
001e |
991-5008
|
18/3 replacement power cord 50 foot (beige) |
$43.29
|
1 |
(NON-OEM) |
ships same day |
002 |
182-0140
|
Strain relief |
$0.99
|
1 |
|
ships same day |
003a |
182-0100
|
Cord hook set |
$5.50
|
1 |
|
ships same day |
003b |
182-0073
|
Cord retainer |
$4.80
|
1 |
(dust cup models) |
usually ships 6-16 days |
004 |
181-0297
|
Warning decal |
$11.99
|
1 |
|
usually ships 1-5 days |
005 |
182-0008
|
Motor mounting screw |
$4.61
|
2 |
|
usually ships 6-16 days |
006 |
182-0175
|
Handle socket shield |
$2.75
|
1 |
|
usually ships 6-16 days |
007 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
$0.99
|
2 |
|
ships same day |
008 |
182-0079
|
Handle socket assembly |
$10.44
|
1 |
|
ships same day |
009 |
182-0081
|
Bolt 10-24 x 5/8 carriage head |
$5.50
|
2 |
|
ships same day |
010a |
272-5187
|
Cloth bag assembly (black) (sold individually) |
$60.73
|
1 |
(includes 011, 012, 018) |
usually ships 16-41 days |
010b |
182-0097
|
Cloth bag assembly (red) |
$39.99
|
1 |
(includes 011, 012, 018) |
ships same day |
010c |
272-5193
|
Cloth vacuum bag with zipper (black) |
$73.68
|
|
(including paper and bag spring) |
ships same day |
010d |
991-9070
|
Cloth bag with full zipper |
$29.99
|
1 |
|
ships same day |
010e |
991-9092
|
Shake out cloth bag |
$158.86
|
1 |
|
ships same day |
010f |
991-9035
|
Cloth shake out bag w/liner (red) (S12 and S16) |
$15.92
|
1 |
(NON-OEM) |
ships same day |
10g |
991-9035
|
Cloth shake out bag w/liner (red) (S12 and S16) |
$15.92
|
1 |
(NON-OEM) |
ships same day |
011 |
182-0143
|
Bag clip |
$6.82
|
1 |
|
ships same day |
012 |
182-0144
|
Bag spring |
$4.61
|
1 |
|
usually ships 6-16 days |
013 |
182-0082
|
Handle grip |
$4.61
|
1 |
|
usually ships 5-16 days |
014a |
272-6264
|
Handle assembly |
$59.17
|
1 |
(12DC) (includes 003-009, 013, 14c and 016-017) |
usually ships 16-41 days |
014b |
182-0074
|
Upper handle assembly |
$22.07
|
1 |
(includes 013) |
usually ships 6-16 days |
016 |
182-0075
|
Screw and nut assembly |
$5.50
|
2 |
|
ships same day |
017 |
182-0138
|
Lower handle tube |
$13.79
|
1 |
|
usually ships 6-16 days |
018a |
182-0148
|
Bag adapter |
$8.45
|
1 |
|
usually ships 6-16 days |
018b |
182-0145
|
Bag adapter gasket |
$2.75
|
1 |
|
usually ships 6-16 days |
018c |
182-0146
|
Washer |
$3.95
|
1 |
|
usually ships 1-5 days |
018d |
182-0147
|
Rivet package |
$6.60
|
1 |
|
usually ships 1-5 days |
018e |
182-0066
|
Rivet (OBSOLETE) |
$3.29
|
1 |
|
usually ships 6-16 days |
019 |
182-0034
|
Screw 10-14 x 1/2 pan head plastite |
$4.61
|
1 |
|
ships same day |
023 |
182-0085
|
Pin |
$4.61
|
1 |
|
usually ships 6-16 days |
024 |
182-0086
|
Bag lid |
$7.69
|
1 |
|
ships same day |
025 |
182-0087
|
Gasket |
$3.85
|
1 |
|
usually ships 6-16 days |
026 |
182-0088
|
Dust cup support and latch assembly |
$44.86
|
1 |
|
usually ships 6-16 days |
027 |
182-0089
|
Clamp |
$4.61
|
1 |
|
usually ships 6-16 days |
028 |
182-0026
|
Bellows |
$23.84
|
1 |
|
usually ships 6-16 days |
029 |
999-0705
|
Screw 10-24 x 3/4 pan head phillips stainless steel |
$0.99
|
1 |
|
ships same day |
030 |
182-0025
|
Bellows clamp |
$7.81
|
1 |
|
ships same day |
031 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
$0.99
|
1 |
|
ships same day |
032 |
182-0090
|
Steel ring |
$3.29
|
1 |
|
usually ships 1-5 days |
033 |
182-0091
|
Snap hook |
$4.61
|
1 |
|
usually ships 6-16 days |
034a |
182-0092
|
Bag assembly (black) (dust cup) |
$44.72
|
1 |
|
usually ships 6-16 days |
034b |
182-0191
|
Bag assembly (red) (dust cup) |
$39.20
|
1 |
(887 All) |
usually ships 6-16 days |
035 |
182-0093
|
Bag gasket |
$8.28
|
1 |
|
usually ships 6-16 days |
036 |
182-0094
|
Dust cup |
$24.77
|
1 |
|
usually ships 6-16 days |
037 |
182-0095
|
Dust cup assembly |
$131.71
|
1 |
(includes 023-036) |
usually ships 6-16 days |
KIT |
272-6262
|
Dust cup bag kit |
$223.84
|
1 |
(includes 023, 024, 032, 033, 034 and 035) |
usually ships 16-41 days |
KIT |
272-6263
|
Dust cup bellows kit |
$14.51
|
1 |
(includes 027, 028, 029, 030 and 031) |
ships same day |
N/S |
182-0749
|
Garter spring |
$34.62
|
1 |
Holds the paper bag on the tube |
ships same day |
N/S |
182-0150
|
Hardware package (OBSOLETE) |
$8.24
|
1 |
(includes 1 cord retainer set and 2 handle screw assemblies) |
usually ships 3-26 days |
N/S |
172-1635
|
Paper vacuum bag (pkg of 10) |
$17.61
|
1 |
|
usually ships 16-41 days |
N/S |
182-0203
|
Paper vacuum bags F & G style (pkg of 5) |
$13.01
|
1 |
(OEM) |
usually ships 6-16 days |
N/S |
991-9039
|
Paper vacuum bags (pkg of 3) |
$2.99
|
1 |
(NON-OEM) |
usually ships 5-12 days |
N/S |
991-9148
|
Paper vacuum bag (pkg of 3) |
$2.73
|
1 |
(NON-OEM) |
usually ships 5-16 days |
N/S |
991-9148
|
Paper vacuum bag (pkg of 3) |
$2.73
|
1 |
(NON-OEM) |
usually ships 5-16 days |
N/S |
991-9013
|
Paper filter bag (pkg of 10) |
$8.75
|
1 |
(NON-OEM) |
ships same day |
