| # | Part | Description | Price | Req | Notes | Availability |
|---|
A1 |
172-8085
|
Speed control kit (OBSOLETE) |
$737.00
|
1 |
|
usually ships 16-41 days |
BT |
N/A
|
Not available |
Call for price
|
|
|
usually ships 3-26 days |
D1 |
172-0236
|
Diode rectifier assembly |
$31.83
|
1 |
|
ships same day |
E1 |
172-1006
|
24V single control assembly |
$280.48
|
1 |
|
usually ships 1-5 days |
F1 |
172-0228
|
5amp circuit breaker (OBSOLETE) |
$79.20
|
1 |
|
usually ships 16-41 days |
F2 |
172-0227
|
20amp circuit breaker (OBSOLETE) |
$69.96
|
1 |
|
usually ships 16-41 days |
F4 |
991-1633
|
70amp circuit breaker |
$57.60
|
1 |
|
usually ships 3-19 days |
H1 |
172-0220
|
Green light (OBSOLETE) |
$17.90
|
1 |
|
usually ships 16-41 days |
H2 |
172-0504
|
Blue light (OBSOLETE) |
$7.70
|
1 |
|
usually ships 16-41 days |
K1 |
172-0082
|
Solenoid contactor (OBSOLETE) |
$83.82
|
1 |
|
usually ships 16-41 days |
L1 |
172-2094
|
Solenoid valve assembly |
$549.82
|
1 |
|
usually ships 16-41 days |
M1a |
172-0120
|
24V 2 stage vacuum motor dual ball tangential (OBSOLETE) |
$261.59
|
1 |
(OEM) |
usually ships 16-41 days |
M1b |
991-1203
|
24V 2 stage vacuum motor tangential |
$91.58
|
1 |
(NON-OEM) |
ships same day |
M2 |
172-0349
|
Brush motor |
$1,760.00
|
1 |
|
usually ships 1-5 days |
M3 |
172-9899
|
24V drive motor (OBSOLETE) |
$1,621.62
|
1 |
|
usually ships 1-5 days |
M4 |
172-8921
|
Actuator |
$537.16
|
1 |
|
usually ships 16-41 days |
P |
172-2302
|
Battery meter |
$90.59
|
1 |
|
usually ships 16-41 days |
R |
172-2039
|
5K potentiometer |
$61.41
|
1 |
|
ships same day |
S1 |
172-0235
|
Switch assembly (OBSOLETE) |
$179.06
|
1 |
|
usually ships 16-41 days |
S2 |
172-6004
|
Toggle switch |
$44.79
|
1 |
|
usually ships 16-41 days |
S3 |
172-2301
|
Snap switch |
$46.22
|
1 |
|
usually ships 16-41 days |
S4 |
172-0219
|
Rocker switch |
$67.20
|
1 |
|
usually ships 16-41 days |
S5 |
172-2157
|
Rocker switch DPDT |
$80.86
|
1 |
|
usually ships 16-41 days |
X1 |
N/A
|
Not available |
Call for price
|
1 |
Not available(positive main terminal) |
usually ships 3-26 days |
X10 |
N/A
|
Not available |
Call for price
|
1 |
Not available(actuator motor connector) |
usually ships 3-26 days |
X11 |
N/A
|
Not available |
Call for price
|
1 |
Not available(actuator control module connector) |
usually ships 3-26 days |
X2 |
N/A
|
Not available |
Call for price
|
1 |
(negative main terminal) |
usually ships 3-26 days |
X3 |
172-9841
|
Charger plug assembly (OBSOLETE) |
$131.27
|
1 |
|
usually ships 1-5 days |
