| # | Part | Description | Price | Req | Notes | Availability |
|---|
001 |
N/A
|
Not available |
Call for price
|
1 |
(Battery case weldment) |
usually ships 3-26 days |
002 |
N/A
|
Not available |
Call for price
|
1 |
(Cover) |
usually ships 3-26 days |
003 |
N/A
|
Not available |
Call for price
|
1 |
(Support bracket weldment) |
usually ships 3-26 days |
004 |
N/A
|
Not available |
Call for price
|
1 |
(Cover weldment) |
usually ships 3-26 days |
005 |
N/A
|
Not available |
Call for price
|
1 |
(not available) Battery Spacer for 200B only |
usually ships 3-26 days |
006 |
172-2207
|
Nut 1/4-20 clamp |
$8.03
|
8 |
|
usually ships 1-5 days |
007 |
172-2208
|
Sealing washer |
$10.56
|
3 |
|
usually ships 16-41 days |
008 |
172-2209
|
Raw trim |
$13.40
|
15 |
|
usually ships 16-41 days |
009 |
999-0018
|
Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated |
$0.99
|
6 |
Loc |
ships same day |
010 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
$0.99
|
2 |
|
ships same day |
011 |
999-0361
|
Bolt 1/4-20 x 3/8 hex head grade 5 zinc |
$4.17
|
2 |
|
ships same day |
012 |
172-0027
|
Slide latch (OBSOLETE) |
$22.88
|
1 |
|
usually ships 1-5 days |
013 |
172-2210
|
Plastic tray (OBSOLETE) |
$72.47
|
1 |
|
usually ships 1-5 days |
014 |
172-2211
|
Gasket |
$10.56
|
1 |
|
usually ships 1-5 days |
015 |
999-0029
|
Bolt 5/16-18 x 1/2 hex head plain finish |
$0.99
|
2 |
Loc |
ships same day |
016 |
999-0633
|
Bolt 1/4-20 x 5/8 hex head stainless steel |
$0.99
|
1 |
Loc |
ships same day |
017 |
999-0694
|
Screw 1/4-20 x 1/2 flat head phillips zinc plated |
$0.99
|
1 |
Loc |
ships same day |
018 |
N/A
|
Not available |
Call for price
|
1 |
(Gasket) |
usually ships 3-26 days |
019 |
N/A
|
Not available |
Call for price
|
1 |
(Sealing washer) |
usually ships 3-26 days |
