| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
240-2240
|
Recovery tank |
1 |
|
|
2 |
240-2188
|
Gasket |
1 |
|
|
3 |
240-2189
|
Drain cap |
1 |
|
|
4 |
240-6023
|
BUSHING TANK RUBBER BLACK |
1 |
|
|
5 |
240-6024
|
BUSHING TANK RUBBER GREY |
1 |
|
|
6 |
240-2243
|
Suction kit |
1 |
(includes 9-10) |
|
7 |
240-2244
|
Float kit |
1 |
(includes 11-19) |
|
8 |
240-6017
|
RECOVERY TANK LID KIT |
1 |
(includes 20-24) |
|
9 |
240-2246
|
Outlet base |
1 |
|
|
10 |
240-2247
|
Cover gasket |
1 |
|
|
11 |
240-2248
|
Screw |
1 |
|
|
12 |
240-2249
|
Guide base |
1 |
|
|
13 |
240-2250
|
Base plug |
1 |
|
|
14 |
240-2247
|
Cover gasket |
1 |
|
|
15 |
240-2251
|
Plug cover |
1 |
|
|
16 |
240-2252
|
Vacuum base |
1 |
|
|
17 |
240-2253
|
O-ring |
1 |
|
|
18 |
240-2254
|
Vacuum cover |
1 |
|
|
19 |
240-0462
|
Screw M4 x 16mm self-tapping |
2 |
|
|
20 |
270-8568
|
Lid seal (OBSOLETE) |
1 |
|
|
21 |
270-8569
|
Seat for lid (OBSOLETE) |
1 |
|
|
22 |
240-5972
|
SEAL FOR LID |
1 |
|
|
23 |
240-6503
|
CLEAR LID |
1 |
|
|
24 |
270-8571
|
Screw M4x12 (OBSOLETE) |
6 |
|
|
