| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
160-0054
|
45 degree elbow fitting |
2 |
|
|
2 |
160-0052
|
Fitting 1/4 barb x 1/4mp |
1 |
|
|
4 |
999-1032
|
Screw 1/4-20 x 5/8 hex head stainless steel |
1 |
|
|
7 |
372-2180
|
Screw 3/8-16 x 1/2 |
3 |
|
|
8 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
2 |
|
|
10 |
999-0395
|
Screw 1/4-20 x 5/8 button head socket plain finish |
2 |
|
|
11 |
997-2004
|
Hose clamp |
2 |
|
|
12 |
272-7274
|
Hose clamp |
1 |
|
|
13 |
272-7275
|
Female coupler |
1 |
|
|
14 |
272-7276
|
Regulator (OBSOLETE) |
1 |
|
|
15 |
272-7277
|
12V Lock off assembly (OBSOLETE) |
1 |
|
|
16 |
272-7278
|
90° male elbow (OBSOLETE) |
1 |
|
|
17 |
572-4027
|
Hose |
1 |
|
|
18a |
472-7668
|
ENGINE KIT-603CC CAT-11 |
1 |
(only used on models 56381402, 56381407 and 56381454) |
|
18b |
472-7478
|
ENGINE KIT-603CC MUFF |
1 |
(only used on models 56381404, 56381405 and 56381406) |
|
19 |
472-7457
|
MANIFOLD-EXHAUST |
1 |
|
|
20a |
272-7250
|
Catalyst muffler |
1 |
(only used on models 56381402, 56381407 and 56381454) |
|
20b |
272-7280
|
Muffler |
1 |
(only used on models 56381404, 56381405 and 56381406) |
|
22 |
272-7281
|
Vac hose |
1 |
|
|
24 |
170-3180
|
3/8 inch propane hose |
1 |
|
|
25 |
169-0142
|
Muffler plug |
1 |
|
|
26 |
170-3181
|
Check valve |
1 |
|
|
28 |
999-0060
|
Washer 1/4 split lock plain finish |
1 |
|
|
29a |
161-0004
|
Steel propane tank |
1 |
|
|
29b |
161-0003
|
Aluminum propane tank |
1 |
(polished) |
|
29c |
370-6878
|
TANK LP ALUM 80 |
1 |
(gray) |
|
30 |
272-7283
|
Exhaust gasket |
1 |
|
|
31 |
272-7284
|
Muffler clamp |
1 |
|
|
32 |
999-0659
|
Washer 3/8 medium split lock stainless steel |
3 |
|
|
33 |
999-0028
|
Washer 5/16 split lock plain finish |
2 |
|
|
34 |
472-8012
|
ADAPTER-.25MPT X .25FPT-BRASS (OBSOLETE) |
1 |
|
|
N/S |
272-7282
|
Exhaust clamp |
1 |
|
|
