| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
170-5812
|
Plate base (OBSOLETE) |
1 |
|
|
002 |
170-5813
|
Rocker switch (OBSOLETE) |
1 |
Illuminated |
|
003 |
170-6286
|
Base plate catch (OBSOLETE) |
1 |
|
|
004 |
170-6170
|
Rivet 1/8 pop |
2 |
|
|
005 |
170-3342
|
Vacuum tank gasket (OBSOLETE) |
1 |
|
|
006 |
170-6287
|
2 Stage 120 volt vacuum motor (OBSOLETE) |
1 |
|
|
007 |
170-6288
|
Vacuum motor bracket (OBSOLETE) |
1 |
|
|
008 |
999-0723
|
Screw 10-32 x 1/2 pan head slotted stainless steel |
4 |
|
|
009 |
170-6289
|
Pump bracket (OBSOLETE) |
1 |
|
|
010 |
170-3341
|
Pump 120V flojet (OBSOLETE) |
1 |
|
|
011 |
999-1087
|
Bolt M6-1 x 25mm hex head stainless steel |
2 |
|
|
012 |
999-0723
|
Screw 10-32 x 1/2 pan head slotted stainless steel |
2 |
|
|
013 |
999-1087
|
Bolt M6-1 x 25mm hex head stainless steel |
2 |
|
|
