| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
170-1186
|
Connection box (OBSOLETE) |
1 |
|
|
002 |
170-1187
|
Gasket (OBSOLETE) |
1 |
|
|
003 |
999-1261
|
Washer M6 flat stainless steel |
1 |
|
|
004 |
170-1188
|
P.C. Board 12v DC/ 24v AC (OBSOLETE) |
1 |
|
|
005 |
170-1189
|
Waher M4 (OBSOLETE) |
4 |
|
|
006 |
170-1190
|
Nut M4 lock (OBSOLETE) |
4 |
|
|
007 |
170-1191
|
Fuse |
2 |
|
|
008 |
170-1192
|
Fuse 6, 3 A |
1 |
|
|
009 |
170-1193
|
Holder for fuse (OBSOLETE) |
1 |
|
|
011 |
170-1194
|
Socket with nut (OBSOLETE) |
1 |
|
|
012 |
170-1195
|
Cable grommet |
6 |
|
|
013 |
170-1007
|
Rubber seal (OBSOLETE) |
2 |
|
|
014 |
170-0954
|
Nut M6 hex lock (OBSOLETE) |
4 |
|
|
015 |
170-0953
|
Screw 6mm x 16 set (OBSOLETE) |
5 |
|
|
017 |
170-1196
|
Nut M4 (OBSOLETE) |
4 |
|
|
018 |
170-1197
|
Waher M4 (OBSOLETE) |
4 |
|
|
019 |
170-1198
|
Inspection (OBSOLETE) |
1 |
|
|
020 |
170-1199
|
Gasket (OBSOLETE) |
1 |
|
|
021 |
170-1200
|
Screw M3 x 6 (OBSOLETE) |
4 |
|
|
022 |
170-1201
|
Setting of control unit (OBSOLETE) |
1 |
|
|
023 |
170-1185
|
Lock nut |
1 |
|
|
024 |
170-1202
|
Red gasket (OBSOLETE) |
1 |
|
|
025 |
170-1203
|
Control unit |
1 |
|
|
028 |
170-1206
|
Right gasket N/A |
1 |
|
|
029 |
170-1207
|
Left gasket N/A |
1 |
|
|
030 |
170-1208
|
Complete black adjusting knob |
1 |
|
|
041 |
170-0998
|
Pressure gauge pipe |
1 |
|
|
042 |
170-1209
|
Pressure gauge fitting |
1 |
|
|
043 |
170-1210
|
Gasket (OBSOLETE) |
1 |
|
|
044 |
170-1211
|
Connection box and transfer cover (OBSOLETE) |
1 |
|
|
046 |
170-1212
|
Pressure gauge |
1 |
|
|
047 |
170-1213
|
Choke cable (OBSOLETE) |
2 |
|
|
048 |
170-1214
|
Fuse 15a 32v (OBSOLETE) |
1 |
|
|
050 |
170-1204
|
Ignition lock (OBSOLETE) |
|
|
|
051 |
170-1205
|
Key (OBSOLETE) |
1 |
|
|
