| # | Part | Description |
Req | Notes | Availability |
|---|
000 |
170-1117
|
Complete air distributor (OBSOLETE) |
|
|
|
001 |
170-1172
|
Ignition electrode short (OBSOLETE) |
2 |
|
|
002 |
170-1173
|
Rubber lead in |
2 |
|
|
003 |
170-1174
|
Cover |
1 |
|
|
004 |
170-1175
|
Clamp |
1 |
|
|
005 |
170-1176
|
Screw M6 x 12 (OBSOLETE) |
1 |
|
|
006 |
170-1177
|
Air distributor (OBSOLETE) |
1 |
|
|
007 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
1 |
|
|
008 |
170-1179
|
Nut |
1 |
|
|
009 |
N/A
|
Not available |
1 |
(Electrode holder) |
|
010 |
170-1181
|
Nozzel holder |
1 |
|
|
011 |
170-1182
|
Nozzel |
1 |
|
|
012 |
170-1183
|
Lightning symbol (OBSOLETE) |
1 |
|
|
013 |
170-1184
|
Flame control sensor |
1 |
|
|
014 |
170-1185
|
Lock nut |
1 |
|
|
