| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
170-1025
|
Engine 390 Honda for KEW (OBSOLETE) |
1 |
|
|
002 |
170-1026
|
Key |
1 |
|
|
003 |
170-1027
|
O-Ring (OBSOLETE) |
1 |
|
|
004 |
170-1028
|
Tightening ring |
1 |
|
|
005 |
170-1029
|
Attachment plate (OBSOLETE) |
1 |
|
|
009 |
170-1030
|
Washer M8 spring |
2 |
|
|
010 |
170-1031
|
Screw M8 x 30 set |
2 |
|
|
011 |
170-1032
|
Washer (OBSOLETE) |
2 |
|
|
012 |
170-1033
|
Screw M8 x 20 |
2 |
|
|
021 |
999-1900
|
Screw M8-1.25 x 25mm socket hex head zinc finish |
2 |
|
|
022 |
170-1030
|
Washer M8 spring |
4 |
|
|
023 |
170-1036
|
Screw M8 x 35 (OBSOLETE) |
2 |
|
|
024 |
170-0955
|
Washer 8mm (OBSOLETE) |
2 |
|
|
025 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
1 |
|
|
027 |
170-1037
|
D-Bearing cover - front (OBSOLETE) |
1 |
|
|
028 |
170-1038
|
D-Bearing cover - complete (OBSOLETE) |
|
|
|
030 |
170-1039
|
Washer |
1 |
|
|
032 |
170-1040
|
Guide pin |
1 |
|
|
033 |
170-1041
|
Bearing track |
1 |
|
|
035 |
170-1049
|
Axial roller bearing |
1 |
|
|
036 |
170-1044
|
Wobble disc 15 (OBSOLETE) |
1 |
|
|
037 |
170-1045
|
Set Screw (OBSOLETE) |
1 |
|
|
038 |
170-1046
|
Washer |
1 |
|
|
039 |
170-1047
|
Stud |
8 |
|
|
040 |
170-1048
|
Needle bearing |
1 |
|
|
041 |
170-1049
|
Axial roller bearing |
1 |
|
|
043 |
170-1050
|
Gasket set 03 (OBSOLETE) |
|
|
|
