| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
170-2877
|
Carpet tool |
1 |
|
|
001b |
170-3876
|
Floor tool |
1 |
|
|
001c |
170-3870
|
Bumper |
1 |
|
|
004 |
170-3871
|
Carpet shoe |
1 |
|
|
005 |
170-2878
|
Lower wand assembly |
1 |
|
|
006 |
170-1661
|
Pin |
1 |
|
|
009 |
170-2874
|
Upper wand |
1 |
|
|
010 |
170-4032
|
1 1/2 Inch x 10 ft vacuum hose (OBSOLETE) |
1 |
|
|
011 |
170-2875
|
Crevice tool |
1 |
|
|
012 |
170-2876
|
3 inch dusting brush |
1 |
|
|
013 |
170-3873
|
Housing |
1 |
|
|
014 |
170-3874
|
Bristle |
1 |
|
|
015 |
170-3277
|
Roller combi-dry nozzle |
1 |
|
|
016 |
170-3661
|
Squeegee tool assembly (OBSOLETE) |
1 |
|
|
017 |
170-3876
|
Floor tool |
1 |
|
|
018 |
170-3870
|
Bumper |
|
|
|
019 |
170-3878
|
Squeegee rear tool |
1 |
|
|
020 |
170-3879
|
Squeegee blade (OBSOLETE) |
1 |
|
|
021 |
170-3880
|
Squeegee front shoe |
1 |
|
|
