| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$0.99
|
2 |
|
usually ships 12-18 days |
2 |
170-9148
|
Tension rod (OBSOLETE) |
$7.59
|
1 |
|
usually ships 1-5 days |
3 |
170-9149
|
Pedal (OBSOLETE) |
$133.87
|
1 |
|
usually ships 1-5 days |
4 |
999-9099
|
Washer M10 flat stainless steel |
$0.99
|
1 |
|
ships same day |
5 |
272-8385
|
Screw hex head 3 9/10 X 13 |
$34.10
|
2 |
|
usually ships 1-5 days |
6 |
172-4821
|
Washer M6 flat |
$6.78
|
3 |
|
usually ships 1-5 days |
7 |
N/A
|
Not available |
Call for price
|
3 |
(Screw) |
usually ships 3-26 days |
8 |
172-3747
|
Dowel (OBSOLETE) |
$11.69
|
1 |
|
usually ships 17-28 days |
9 |
170-9150
|
Gasket (OBSOLETE) |
$13.06
|
1 |
|
usually ships 1-5 days |
10 |
170-9151
|
Pedal gasket |
$12.31
|
1 |
|
usually ships 1-5 days |
11 |
170-9152
|
Pedal harness |
$206.91
|
1 |
|
usually ships 17-28 days |
12 |
170-9153
|
Speed control pedal support (OBSOLETE) |
$77.22
|
1 |
|
usually ships 1-5 days |
13 |
170-9154
|
Washer (OBSOLETE) |
$10.12
|
1 |
|
usually ships 1-5 days |
14 |
N/A
|
Not available |
Call for price
|
1 |
(connecting rod) |
usually ships 3-26 days |
15 |
170-9155
|
Rubber pedal cover |
$23.01
|
1 |
|
usually ships 1-5 days |
16 |
272-7164
|
Elbow joint |
$24.60
|
1 |
|
ships same day |
17 |
172-4822
|
Washer M6 split |
$10.85
|
3 |
|
usually ships 1-5 days |
18 |
170-9156
|
Pedal kit (OBSOLETE) |
$380.05
|
1 |
(includes 1-17) |
usually ships 17-28 days |
