| # | Part | Description | Price | Req | Notes | Availability |
|---|
001 |
170-7854
|
Drive assembly (OBSOLETE) |
$2,900.50
|
1 |
|
usually ships 16-41 days |
002 |
170-7855
|
Drive mounting plate (OBSOLETE) |
$58.21
|
1 |
|
usually ships 1-5 days |
003 |
170-7856
|
Drive mounting bracket (OBSOLETE) |
$74.14
|
1 |
|
usually ships 1-5 days |
004 |
170-6791
|
Sprocket steering assembly |
$528.00
|
1 |
|
usually ships 1-5 days |
005 |
170-6791
|
Sprocket steering assembly |
$528.00
|
1 |
|
usually ships 1-5 days |
006 |
170-6792
|
Chain steering |
$96.51
|
1 |
|
usually ships 1-5 days |
007 |
999-0188
|
Nut 3/8-16 nylon insert lock zinc plated |
$0.99
|
8 |
|
ships same day |
008 |
170-7858
|
Motor wires guide (OBSOLETE) |
Call for price
|
1 |
|
usually ships 1-5 days |
009 |
170-7859
|
Guard wheel (OBSOLETE) |
$86.13
|
1 |
|
usually ships 1-5 days |
010 |
999-0031
|
Bolt 5/16-18 x 1 hex head grade 5 zinc plated |
$0.99
|
2 |
|
ships same day |
011 |
170-6686
|
Washer 5/16 lock |
$10.56
|
2 |
|
usually ships 16-41 days |
012 |
999-0038
|
Bolt 3/8-16 x 1 hex head grade 5 zinc plated |
$1.87
|
8 |
|
ships same day |
013 |
999-0350
|
Bolt 3/8-16 x 1 1/2 hex head grade 5 zinc plated |
$0.99
|
4 |
|
ships same day |
014 |
170-6782
|
Washer 3/4 x 25/64 x 3/32 flat |
$11.99
|
10 |
|
usually ships 16-41 days |
015 |
170-6752
|
Washer 3/8 lock split plated |
$11.99
|
8 |
|
usually ships 1-5 days |
016 |
170-7860
|
Washer |
$11.99
|
4 |
|
usually ships 1-5 days |
017 |
999-0752
|
Nut 3/4-16 hex jam zinc plated |
$0.99
|
1 |
|
ships same day |
018 |
170-7861
|
Screw 3/8 - 24 x 3/4 hex head |
$10.52
|
4 |
|
usually ships 1-5 days |
