| # | Part | Description | Price | Req | Notes | Availability |
|---|
10 |
170-8399
|
Actuator |
$722.15
|
1 |
|
usually ships 1-5 days |
12 |
370-4316
|
ROD SB OPTION SC5730 |
$48.07
|
1 |
|
usually ships 17-28 days |
16 |
370-2658
|
ARM-SIDE BROOM LIFT (OBSOLETE) |
$11.66
|
1 |
|
usually ships 17-28 days |
17 |
370-3981
|
KNOB SB OPTION SC5730 |
$11.66
|
1 |
|
usually ships 17-28 days |
22 |
999-0344
|
Bolt 1/4-20 x 1 1/2 hex head plain finish |
$0.99
|
2 |
|
ships same day |
23 |
170-6782
|
Washer 3/4 x 25/64 x 3/32 flat |
$12.31
|
12 |
|
usually ships 17-28 days |
24 |
999-0038
|
Bolt 3/8-16 x 1 hex head grade 5 zinc plated |
$1.87
|
6 |
|
ships same day |
25 |
999-0324
|
Nut 3/8-16 nylon insert lock jam zinc plated |
$0.99
|
6 |
|
ships same day |
27 |
170-7782
|
Cotter hair pin (OBSOLETE) |
$9.27
|
1 |
|
usually ships 1-5 days |
