| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
N/A
|
Not available |
1 |
Left hand frame assembly |
|
002 |
N/A
|
Not available |
1 |
Caster bracket |
|
003 |
N/A
|
Not available |
3 |
Screw |
|
004 |
170-8034
|
Screw 8mm x 1.25 x 20 hex head (OBSOLETE) |
9 |
|
|
005 |
999-0028
|
Washer 5/16 split lock plain finish |
16 |
|
|
006 |
170-5787
|
Nut M8 x 1.25 |
6 |
|
|
007a |
991-2011
|
Caster wheel assembly |
2 |
|
|
007b |
170-7201
|
Caster wheel |
|
|
|
008 |
N/A
|
Not available |
10 |
Washer 5/8 plain |
|
009 |
N/A
|
Not available |
1 |
Squeegee pivot bracket |
|
010 |
N/A
|
Not available |
1 |
Squeegee bracket |
|
011 |
170-2907
|
Elbow 1/8 x 11/64 |
1 |
|
|
012 |
170-0454
|
Squeegee bracket guide |
1 |
|
|
013 |
170-2908
|
Brush lift diaphragm |
1 |
|
|
014 |
170-2095
|
Diaphragm clamp (OBSOLETE) |
1 |
|
|
015 |
170-2909
|
Squeegee retainer guide (OBSOLETE) |
1 |
|
|
016 |
N/A
|
Not available |
4 |
Screw |
|
017 |
N/A
|
Not available |
1 |
Squeegee pivot bracket assembly |
|
018 |
170-0452
|
Squeegee pivot shaft (OBSOLETE) |
1 |
|
|
019 |
997-2500
|
Cotter pin |
2 |
|
|
020 |
170-0005
|
Squeegee pad |
1 |
|
|
021 |
999-0060
|
Washer 1/4 split lock plain finish |
6 |
|
|
023 |
170-0449
|
Squeegee spring (OBSOLETE) |
1 |
|
|
024 |
N/A
|
Not available |
1 |
Spring |
|
025 |
170-0446
|
Spring coupling |
1 |
|
|
026 |
170-0447
|
Squeegee locking pin |
1 |
|
|
027 |
N/A
|
Not available |
7 |
Screw |
|
028 |
999-0016
|
Washer 1/4 flat plain finish |
12 |
|
|
029 |
170-2911
|
Squeegee assembly retainer (OBSOLETE) |
2 |
|
|
030 |
170-0445
|
Center front retainer (OBSOLETE) |
1 |
|
|
031 |
170-0443
|
Squeegee blade front (OBSOLETE) |
1 |
|
|
032 |
170-0442
|
Squeegee housing (OBSOLETE) |
1 |
|
|
033 |
170-0440
|
Squeegee blade tan 30 3/4 inch (OBSOLETE) |
1 |
|
|
034 |
170-0439
|
Squeegee blade 31 inch rear (black) (OBSOLETE) |
1 |
|
|
035 |
170-0437
|
Squeegee blade rear retainer |
2 |
|
|
036 |
170-2913
|
Nut M6 x 1 hex stop (OBSOLETE) |
4 |
|
|
037 |
170-0438
|
Center rear retainer (OBSOLETE) |
1 |
|
|
038 |
170-0007
|
Squeegee hose with cuffs |
1 |
|
|
039 |
999-1087
|
Bolt M6-1 x 25mm hex head stainless steel |
6 |
|
|
040 |
170-0436
|
Squeegee frame right hand (OBSOLETE) |
1 |
|
|
041 |
170-0435
|
Squeegee frame left hand (OBSOLETE) |
1 |
|
|
042 |
170-0441
|
Squeege blade rear support |
2 |
|
|
043 |
170-5765
|
Squeegee frame right hand (OBSOLETE) |
1 |
|
|
044 |
170-5764
|
Squeegee frame left hand (OBSOLETE) |
1 |
|
|
045 |
170-0457
|
Strap (OBSOLETE) |
2 |
|
|
046 |
170-2914
|
Squeegee assembly retainer (OBSOLETE) |
2 |
|
|
047 |
170-0712
|
Squeegee blade |
1 |
|
|
048 |
170-5769
|
Squeegee blade rear support |
2 |
|
|
049 |
170-0711
|
Squeegee blade front (OBSOLETE) |
1 |
|
|
050 |
170-5767
|
Squeegee blade back up |
1 |
|
|
051 |
170-0566
|
Squeegee label (OBSOLETE) |
2 |
|
|
052 |
N/A
|
Not available |
1 |
Clamp |
|
