| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
997-2007
|
Hose clamp |
1 |
|
|
002 |
170-1946
|
Drain hose |
1 |
|
|
003 |
170-1947
|
Solution tank (OBSOLETE) |
1 |
|
|
004 |
170-7101
|
Battery drain valve |
1 |
|
|
005 |
997-2002
|
Hose clamp #6 |
6 |
|
|
006 |
170-7018
|
Hose |
1 |
|
|
007 |
170-1948
|
Solution hose adapter |
1 |
|
|
008 |
170-0033
|
Solution hose |
2 |
|
|
009 |
170-1949
|
Female adapter |
1 |
|
|
010 |
164-0065
|
Filter screen |
1 |
|
|
011 |
170-0264
|
Hose barb |
1 |
|
|
012 |
170-1953
|
Solution shut-off valve assembly |
1 |
|
|
013 |
170-1920
|
Solenoid valve |
1 |
|
|
014 |
170-7013
|
Solution splitter |
1 |
|
|
015 |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
2 |
|
|
016 |
209-2377
|
Latch and strike |
1 |
|
|
017 |
999-0852
|
Screw 8-32 x 1 1/4 truss head slotted stainless steel |
2 |
|
|
018a |
170-1951
|
Solution fill strainer (OBSOLETE) |
1 |
|
|
018b |
170-1951
|
Solution fill strainer (OBSOLETE) |
1 |
|
|
019 |
170-7372
|
Tank support bracket (OBSOLETE) |
1 |
|
|
020 |
999-0060
|
Washer 1/4 split lock plain finish |
2 |
|
|
021 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
2 |
|
|
022 |
170-1953
|
Solution shut-off valve assembly |
1 |
|
|
KIT |
170-1955
|
Solution fill kit |
1 |
|
|
N/S |
170-1954
|
Funnel (OBSOLETE) |
1 |
|
|
