| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
170-2329
|
handle bracket (obsolete) |
1 |
|
|
002 |
N/A
|
Not available |
1 |
Not available (nameplate) |
|
003 |
N/A
|
Not available |
1 |
Not available (index mark label) |
|
004 |
170-2330
|
Brush board assembly (OBSOLETE) |
1 |
|
|
005 |
372-1648
|
Carbon brush assembly |
4 |
|
|
006 |
372-1685
|
Springs |
4 |
|
|
007 |
170-1504
|
Screw |
3 |
|
|
008 |
170-0379
|
Wave washer |
1 |
|
|
009 |
170-0378
|
Commutator bracket (OBSOLETE) |
1 |
|
|
010 |
170-2333
|
Lead assembly (OBSOLETE) |
1 |
|
|
011 |
170-2334
|
Lead assembly (OBSOLETE) |
1 |
|
|
012 |
170-0009
|
Connector housing |
2 |
|
|
013 |
170-2335
|
Strain relief (OBSOLETE) |
1 |
|
|
014 |
170-0417
|
Communicator cover bracket (OBSOLETE) |
1 |
|
|
015 |
999-0056
|
Screw 10-32 x 3/8 round head slotted zinc plated |
3 |
|
|
016 |
170-0321
|
Front end bearing |
1 |
|
|
017 |
164-0132
|
Square keyway 1/4 x 1/4 |
1 |
|
|
018 |
170-2338
|
Armature assembly (OBSOLETE) |
1 |
|
|
019 |
372-1890
|
Bearing (rear) |
1 |
|
|
020 |
170-0418
|
Pulley end bell bracket |
1 |
|
|
021 |
170-0382
|
Oil seal |
1 |
|
|
022 |
N/A
|
Not available |
2 |
Not available (thru bolt) |
|
