| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
170-0504
|
Spring plate (OBSOLETE) |
2 |
Spring plate |
|
002 |
170-0505
|
Tube Assy Centering (OBSOLETE) |
1 |
Centering tube assembly |
|
003 |
997-2500
|
Cotter pin |
4 |
|
|
004 |
170-0127
|
Brake spring |
2 |
|
|
005 |
170-0506
|
1/4 inch diameter pin (OBSOLETE) |
1 |
|
|
006 |
373-3020
|
Pin roll |
1 |
|
|
007 |
170-0508
|
Centering rod (FSO) (OBSOLETE) |
1 |
|
|
008 |
170-0509
|
Switch rack (OBSOLETE) |
1 |
|
|
009 |
999-0460
|
Nut 10-32 hex |
1 |
|
|
010 |
170-0511
|
Ball joint assembly (OBSOLETE) |
1 |
|
|
011 |
170-0512
|
Switch actuator arm (FSO) (OBSOLETE) |
1 |
|
|
012 |
999-0160
|
Washer 1/4 x 1 1/4 fender zinc plated |
1 |
|
|
013 |
999-0028
|
Washer 5/16 split lock plain finish |
4 |
|
|
014 |
999-0132
|
Bolt 5/16-18 x 3/4 hex head grade 5 zinc plated |
1 |
|
|
015 |
170-0513
|
Control housing (OBSOLETE) |
1 |
|
|
016 |
170-0514
|
Gasket console panel (OBSOLETE) |
1 |
|
|
017 |
N/A
|
Not available |
1 |
Handle pin |
|
018 |
N/A
|
Not available |
2 |
(not available) Pin 3/16 inch diameter |
|
019 |
170-0517
|
Traverse switch harness assembly (OBSOLETE) |
1 |
|
|
020 |
999-0300
|
Bolt 1/4-20 x 7/8 hex head grade 5 zinc plated |
1 |
|
|
021 |
999-0017
|
Washer 1/4 external star lock |
1 |
|
|
022 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
1 |
|
|
023 |
N/A
|
Not available |
1 |
Rack retainer |
|
024 |
170-0519
|
Housing mount spacer (OBSOLETE) |
1 |
|
|
025 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
5 |
|
|
026 |
999-0069
|
Nut 5/16-18 hex |
2 |
|
|
027 |
999-0162
|
Bolt 5/16-18 x 1 1/4 hex head grade 5 zinc plated |
4 |
|
|
028 |
170-0520
|
Warning label (FSO) (OBSOLETE) |
1 |
|
|
029 |
170-0457
|
Strap (OBSOLETE) |
2 |
|
|
030 |
170-0522
|
Switch (OBSOLETE) |
1 |
|
|
031 |
170-0523
|
Bracket switch (OBSOLETE) |
1 |
Switch bracket |
|
032 |
170-0524
|
Gear spacer (OBSOLETE) |
1 |
|
|
033 |
N/A
|
Not available |
1 |
(Not Available) Gear switch |
|
034 |
999-0149
|
Screw 8-32 x 3/16 cup point socket set alloy plain finish |
2 |
|
|
035 |
999-0185
|
Screw 3/8-16 x 3/4 flat head slotted zinc plated |
2 |
|
|
036 |
170-0526
|
Hinge (OBSOLETE) |
1 |
|
|
037 |
999-0081
|
Screw 1/4-20 x 5/8 pan head slotted zinc |
7 |
|
|
038 |
170-0527
|
Adjusting left hand bracket (OBSOLETE) |
1 |
|
|
039 |
999-0190
|
Nut 1/4-20 hex plain finish |
5 |
|
|
040 |
N/A
|
Not available |
1 |
(Not available) Model/serial number label |
|
041 |
999-0062
|
Nut 10-24 hex |
2 |
|
|
042 |
999-0060
|
Washer 1/4 split lock plain finish |
2 |
|
|
043 |
N/A
|
Not available |
1 |
(Not available) Solution controle with cable |
|
044 |
999-0110
|
Screw 10-16 x 1/2 pan head phillips self-drilling |
8 |
|
|
045 |
170-0529
|
Panel console (OBSOLETE) |
1 |
Console panel |
|
046 |
170-0089
|
Rocker switch (OBSOLETE) |
1 |
(traverse speed) |
|
047 |
170-0001
|
Switch |
2 |
(main and vacuum) |
|
048 |
999-0267
|
Screw 10-24 x 1/2 pan head phillips zinc |
2 |
|
|
049a |
170-0531
|
15amp circuit breaker |
1 |
|
|
049b |
991-8539
|
15amp circuit breaker |
1 |
(NON-OEM) |
|
050 |
991-1632
|
25amp circuit breaker |
2 |
|
|
051 |
170-0532
|
Handle grip (OBSOLETE) |
2 |
|
|
052 |
170-0533
|
Control handle (OBSOLETE) |
1 |
|
|
053 |
170-0534
|
Stationary handle (FSO) (OBSOLETE) |
2 |
|
|
054 |
170-0088
|
Flanged bearing (OBSOLETE) |
2 |
|
|
055 |
170-0541
|
Adjusting right hand bracket (OBSOLETE) |
1 |
|
|
056 |
170-0535
|
Handle pivot pin (OBSOLETE) |
1 |
|
|
057 |
170-5566
|
Switch |
1 |
(Brush lift) |
|
058 |
999-0030
|
Bolt 5/16-18 x 5/8 hex head grade 5 zinc plated |
1 |
|
|
059 |
170-0538
|
Console harness assembly (OBSOLETE) |
1 |
|
|
060 |
170-0539
|
Centering tube (OBSOLETE) |
1 |
|
|
061a |
170-0045
|
20 amp breaker |
1 |
|
|
061b |
991-1617
|
20amp circuit breaker |
1 |
|
|
062 |
N/A
|
Not available |
2 |
(not available) Slide bushing |
|
