| # | Part | Description |
Req | Notes | Availability |
|---|
101 |
N/A
|
Not available |
1 |
(Shock warning decal) |
|
102 |
164-4606
|
Heyco strain relief |
1 |
|
|
104 |
164-9118
|
P clamp |
1 |
|
|
105 |
999-1103
|
Bolt 1/4-20 x 3/4 hex head with nylon patch |
1 |
|
|
106 |
N/A
|
Not available |
1 |
(3 speed switch) |
|
109 |
164-7003
|
Boot cap |
1 |
|
|
115 |
164-7006
|
Motor mount (OBSOLETE) |
1 |
|
|
121 |
164-7009
|
Motor (OBSOLETE) |
1 |
|
|
127 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
1 |
|
|
132a |
164-7013
|
Carpet clamp (OBSOLETE) |
1 |
(includes 132b and 132c) |
|
132c |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
2 |
|
|
136 |
164-7015
|
Rubber foot |
4 |
|
|
